Molex MicroClasp Series Right Angle Through Hole PCB Header, 40 Contact, 2 mm Pitch, 2 Row, Shrouded 55959-4030

Molex 55959-4030 MicroClasp Series right angle through-hole PCB header is a high-quality wire-to-board connector featuring 40 male contacts arranged in two rows with a 2 mm pitch spacing. This shrouded connector is designed for through-hole mounting, making it ideal for secure and reliable electronic component connections on printed circuit boards in various industrial applications.

Constructed from brass contacts with tin plating, it ensures excellent electrical conductivity and corrosion resistance. The polyester housing provides robust insulation and mechanical protection. The connector supports a maximum current of 3A and voltage rating of 250V, suitable for diverse electronics and electrical equipment requirements.

The operating temperature range from -40°C to 105°C makes it adaptable for harsh environments and industrial settings. The 3.2 mm tail pin length facilitates solid soldered connections to PCBs, enhancing mechanical stability and signal integrity.

This 55959-4030 series connector is commonly used in applications including telecommunications equipment, industrial machinery, instrumentation, consumer electronics, and other electronic systems requiring compact, reliable connectors with right angle orientation for PCB layouts.

Designed for wire-to-board applications with right angle orientation. Constructed with brass contacts plated in tin for reliable conductivity. Housing made of durable polyester material for enhanced insulation. Rated for 3A current and up to 250V operating voltage.

Operates reliably between -40°C to 105°C temperature range. 3.2 mm tail pin length for through-hole solder termination. Shrouded design protects contacts and ensures proper mating. Supports 40 male contacts arranged in 2 rows with 2 mm pitch.

This PCB Header is suitable for industrial, manufacturing, electronics, and telecommunications applications requiring dependable PCB interconnection solutions. Explore the Electronics Components category for more advanced PCB connector options at EnvMart.
