Artesyn / Advanced Energy High Performance 75W Isolated DC-DC Converter, 5V DC Output, 15A, 66-160V DC Input, Through ERM75

Artesyn / Advanced Energy ERM75 is a high performance 75 watt isolated DC-DC converter specifically engineered for railway applications and other industrial uses requiring robust power modules. The ERM75 supports a wide input voltage range of 66 to 160 V DC, making it suitable for use with high voltage railway rolling stock equipment and other demanding DC input sources.

This DC-DC converter provides a regulated 5V DC output voltage with a maximum continuous output current of 15A. It is constructed with a durable metal casing and an isolated baseplate, conforming to the compact quarter-brick form factor measuring 57.9 mm in length, 36.8 mm width, and 12.7 mm height, allowing easy integration on printed circuit boards through its through-hole mounting design.

The unit achieves high efficiency up to 89%, minimizing thermal dissipation and enhancing reliability. Its operational temperature range spans from -40°C to +85°C, ensuring reliable function under harsh environmental conditions common in industrial settings. The device offers reinforced electrical insulation rated for 3000 VAC rms to safeguard against voltage breakdowns and includes safety features such as under-voltage shutdown and remote on/off control to protect power systems.

The ERM75 series includes a single output with a high MTBF of 209,000 hours, indicating superior reliability for long-term operation in critical industrial and railway power supply applications. The DIP package type and through-hole mounting enhance mechanical stability and ease of installation compared to surface mount options.

This converter is suited for use in industrial, railway systems, power supply modules, and embedded power designs requiring reliable high input voltage DC-DC conversion. The metal encapsulation and isolated baseplate help manage heat and provide electrical isolation needed for safety compliance in rigorous industrial environments.

75 watt isolated DC-DC Converter module designed for railway and industrial applications. Input voltage range spans from 66V to 160V DC for high voltage equipment compatibility. Output voltage fixed at 5V DC with a maximum output current of 15A.

Compact quarter-brick size with dimensions of 57.9 x 36.8 x 12.7 mm for easy PCB integration. Through hole mounting with fully encapsulated metal case and isolated baseplate ensures durability and safety. High efficiency rating of 89% reduces power losses during operation.

Wide operating temperature range from -40°C to +85°C supports harsh environment use. Reinforced insulation tested to 3000 VAC rms for electrical safety. Features under-voltage shutdown and remote on/off control for system protection.

Single output configuration with a mean time between failures (MTBF) of 209,000 hours. Explore our comprehensive collection of DC/DC converters at EnvMart to find reliable power solutions for your industrial electronics and railway applications.
