Toshiba Inverter Logic IC CMOS Open Drain 5-Pin SOT-353 TC7SZ05FU

The Toshiba TC7SZ05FU is a high-performance inverter logic IC designed for surface mount applications in advanced electronic circuits. It incorporates CMOS input technology and an open drain output configuration within a compact 5-pin SOT-353 package, enabling efficient board space utilization.

This inverter IC operates over a broad supply voltage range from 1.65 V up to 5.5 V, offering designers flexibility in low-voltage to standard logic level systems. It features a high output current capability of ±24 mA minimum at a 3.0 V supply, ensuring reliable driving capacity in various load conditions.

Featuring a wide operating temperature range from −40°C to 125°C, the TC7SZ05FU is suitable for industrial and automotive environments, complying with the AEC-Q100 automotive standard which guarantees stringent reliability and quality.

The device offers super high-speed operation with a typical propagation delay time of 1.9 ns at a 5.0 V supply voltage and a load capacitance of 50 pF, providing rapid switching performance suited for high-frequency logic circuits. The 5.5 V tolerant inputs and power down protection outputs further enhance robustness against voltage spikes and external disturbances.

Constructed in the LMOS logic family with a single inverter element per chip and no Schmitt trigger input, this semiconductor device is ideal for standard inverter logic functions in complex electronics, including industrial automation, telecommunications, computing, and automotive electronic systems.

The small form factor SOT-353 package (2 mm length × 1.25 mm width × 900 µm height) facilitates compact PCB layouts and surface mount assembly. These features make TC7SZ05FU a reliable, versatile component for designing efficient and high-performance integrated logic circuits.

Operates across wide voltage range (1.65 V to 5.5 V) to suit diverse power requirements. High output current of ±24 mA minimum at 3.0 V supply enhances drive capability. Wide operating temperature range (-40°C to 125°C) for harsh environment applications.

High switching speed with 1.9 ns typical propagation delay ensures timing precision. 5.5 V tolerant inputs protect against voltage spikes for dependable operation. Compact, space-saving SOT-353 surface mount package for flexible PCB design.

Complies with AEC-Q100 automotive standard for enhanced quality and reliability. Open drain output suitable for wired-AND logic and pull-up resistor driven circuits. Single inverter element per chip is optimal for inverter circuit implementations.

This Toshiba TC7SZ05FU inverter logic IC is a reliable solution for industry-grade semiconductor applications, ranging from consumer electronics to automotive and industrial control systems. Its design balances performance, robustness, and compactness, enhancing the efficiency and durability of electronic devices. For more industrial and electronic semiconductor components, browse the relevant categories at EnvMart.
