Toshiba 1 2-Input AND Logic Gate, 5-Pin SSOP TC7S08F,LF(T)

Toshiba TC7S08F,LF(T) is a 1 2-Input AND Logic Gate offered in a 5-Pin SSOP package, providing high-speed and low-power performance for electronic circuit designs. This L-MOS CMOS logic gate operates within a wide supply voltage range of 2 to 6 volts, making it versatile for use in various electronic and industrial applications.

It delivers typical propagation delay times of 21ns, suitable for high-speed digital circuits requiring fast response times. The device's compact 5-pin SSOP surface mount package enables efficient board layout and space conservation in PCB assemblies.

Operating over a temperature range from -40°C to 85°C, it ensures reliable performance in diverse environments, including industrial and automotive applications. It supports an output drive capable of 5 LSTTL loads with symmetrical output drive capacity, enabling effective interfacing with other digital components.

Designed for low power dissipation and enhanced noise immunity, the Toshiba TC7S08F,LF(T) belongs to Toshiba's L-MOS high-speed CMOS logic IC series. The device features CMOS input types and digital output, enhancing compatibility in modern electronic designs.

It supports maximum operating voltage up to 6V DC, minimum of 2V DC supply voltage. No Schmitt Trigger input present to maintain standard logic functionality. Maximum operating temperature rated at 85°C ensures suitability for demanding thermal conditions.

Manufactured in Japan, ensuring high quality and reliability.

This Logic Gate is ideal for applications in industrial electronics, consumer electronics, automation systems, and embedded systems where reliable AND logic performance is required.

Explore further Toshiba Semiconductor products and related logic ICs on EnvMart for integrated solutions in complex electronic circuit designs.
