| Country of Origin | India |
|---|---|
| Brand | Toshiba |
| Height | 900μm |
| Length | 2mm |
| Model | TC7SZ86FU |
| Mount Type | Surface |
| Output type | CMOS |
| Input Type | CMOS |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-353 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 5 |
| Number of Elements | 1 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS |
| Logic Function | XOR |
| Minimum Supply Voltage | 1.65V |
| Maximum High Level Output Current | -32mA |
| Maximum Propagation Delay Time @ CL | 6.5ns |
| Maximum Low Level Output Current | 32mA |
| Number of Inputs per Gate | 2 |
Toshiba TC7SZ86FU is a 1 2-Input XOR Logic Gate employing CMOS technology, housed in a 5-pin SOT-353 surface mount package. It offers a wide operating temperature range from -40°C to 125°C, making it suitable for industrial, automotive, and electronic applications requiring temperature resilience.
This logic gate features a high output current capability of ±24 mA minimum at a supply voltage of 3.0 V, providing strong drive capability for connected circuits. It supports super high speed operation with a typical propagation delay time of 2.9 ns at 5.0 V and load capacitance of 50 pF, enabling fast digital signal processing.
The device operates efficiently over a supply voltage range from 1.65 V to 5.5 V and includes 5.5 V tolerant inputs, making it versatile for various power conditions. Additionally, it has power down protection output, enhancing circuit protection during power interruptions.
Its compact 5-pin SOT-353 package supports surface mount technology, which is ideal for modern, high-density printed circuit board layouts. The product meets the automotive standard AEC-Q100 for increased reliability in vehicle electronics.
Wide operating temperature range from -40°C to 125°C ensures stable performance in harsh conditions. High output current drive capability enhances logic performance. Super high speed operation provides quick signal propagation.
Operation voltage range and input tolerance offer flexible power compatibility. Power down protection output safeguards connected circuitry. Compact SOT-353 surface mount package allows space-efficient PCB designs. Automotive grade compliance ensures quality and durability.
This logic gate is ideal for applications in industrial automation, automotive electronics, communications equipment, and general-purpose digital logic circuits. It delivers reliable and efficient XOR logic functionality in a compact and robust form factor.
Explore more semiconductor devices and Logic Gates in the Electronics & Electricals category on EnvMart for your circuit design and industrial needs.
