Samtec MECT Series Right Angle Edge Connector, Surface Mount, 20 Contacts, 0.8 mm Pitch, 2 Row, Solder MECT-110-01-M-D-RA1

Free Delivery in India | Lowest Global Shipping Charges

Samtec MECT Series Right Angle Edge Connector, Surface Mount, 20 Contacts, 0.8 mm Pitch, 2 Row, Solder MECT-110-01-M-D-RA1

Name: Samtec MECT Series Right Angle Edge Connector, Surface Mount, 20 Contacts, 0.8 mm Pitch, 2 Row, Solder MECT-110-01-M-D-RA1
Brand: Samtec
SKU: 146016
Price: 3.68 USD
Availability: InStock



Category Edge Connector Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	265V ac
Brand	Samtec
Orientation	Right Angle
Current	2A
Model	MECT-110-01-M-D-RA1
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	MECT
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	0.8mm
Contact Plating	Gold over Nickel
Number of Contacts	20
Contact Gender	Female
Card Type	Edge
Card Thickness	1mm

Key Features

Features a right angle orientation for compact PCB layouts.
Has 20 gold over nickel plated contacts ensuring excellent conductivity.
Operational temperature range from -55°C to 125°C for diverse environmental conditions.
Supports a current rating of 2A and voltage rating of 265V AC.
Constructed with phosphor bronze contacts and liquid crystal polymer housing for durability.
0.8 mm contact pitch and 2 rows accommodate dense circuit designs.
Termination by soldering provides secure and stable attachment to PCBs.
Compatible with SFP, XFP and XENPAK transceivers for versatile applications.

Product Description

Samtec MECT-110-01-M-D-RA1 is a high-quality right angle edge connector designed for surface mount applications with 20 contacts arranged in two rows and a pitch of 0.8 mm. This connector facilitates dependable electrical connections on printed circuit boards and is optimized for compact PCB designs needing high contact density.

Its gold over nickel plated phosphor bronze contacts ensure reliable signal transmission and resistance to corrosion. The housing is made of liquid crystal polymer, providing excellent insulation and high-temperature resistance, operating efficiently between -55°C and +125°C.

Rated for 2A current and 265V AC voltage, this edge connector supports various communication protocols and interfaces including Gigabit Ethernet, Fibre Channel, and more, making it suitable for use in computer assemblies, telecommunications networks, aerospace systems, and test and measurement instruments.

Installation is straightforward by soldering the connector onto the edge of the PCB, with metallic tracks mating precisely to the contacts to form a secure electrical connection. The compact dimensions (approximately 11 mm length, 5.2 mm width, and 7.4 mm depth) allow it to fit into small enclosures.

Right angle orientation for space-saving PCB layouts. Gold over nickel contact plating for enhanced conductivity and durability. Operational temperature between -55°C and 125°C suits demanding environments. 2A current and 265V AC voltage ratings for medium-voltage applications.

Liquid crystal polymer housing offering insulation and mechanical strength. Dual-row, 20-contact configuration supports multiple circuit connections. Solder termination ensures robust and lasting mounting. Compatible with various transceiver modules for flexible usage.

This Edge Connector is ideal for industrial, telecommunications, aerospace, laboratory, and manufacturing environments where reliable PCB connections are critical. Its rugged design and versatile compatibility make it an essential component for advanced electronic assemblies.
