Molex Straight Edge Connector, Through Hole, 4 Contacts, 2.5 mm Pitch, 2 Row, Press-in 45714-0001

Molex 45714-0001 Straight Edge Connector is an advanced PCB and card-edge interconnect solution engineered for through hole applications requiring high reliability and convenient press-fit termination. Featuring a straight orientation and supporting up to four contacts in two parallel rows with a precise 2.5 mm pitch, this connector is suited for compact and efficient board-to-board or bus-bar connections in electronic devices.

The connector's press-in termination method streamlines assembly, eliminating the need for soldering and offering robust mechanical and electrical retention. Each contact is fabricated from high-grade copper alloy, plated with gold over nickel to ensure outstanding conductivity and long-term corrosion resistance. The device supports up to 40A current per contact and is rated for a maximum voltage of 250V, making it ideal for demanding power and signal interfacing scenarios.

Molex 45714-0001 mates directly with 1.58 mm (0.062 inch) double-sided card edges and bus bar tabs, accommodating flexible stackable configurations. Its isolated segments on opposing contacts facilitate true hot-swapping functionality, meaning systems can be serviced or reconfigured without power-down, a crucial capability for modular and mission-critical industrial environments.

The robust housing is manufactured from liquid crystal polymer (LCP), providing enhanced heat resistance and maintaining structural integrity across temperatures ranging from -40°C up to 105°C. The connector is designed for female contact gender and includes card thickness compatibility at 1.57 mm, fitting standard edge and bus card formats. It is intended for use in environments where compliance and performance are paramount, including industrial control, power distribution, testing, and secure commercial computing assemblies.

This Molex connector supports end-to-end stacking, enabling scalable and space-efficient panel layouts. With reliable press-fit terminations and a straight mounting profile, engineers can leverage its performance for demanding PCB or panel assemblies, reducing downtime and facilitating fast, robust installations. The product is used in power electronics, industrial automation, laboratory instrumentation, and anywhere modular PCB interconnection is needed.

Discover high-performance Edge Connectors from Molex and browse the latest offerings in the PCB and computing interconnect categories at EnvMart.
