Nexperia N-Channel MOSFET, 330 mA, 60 V Enhancement Mode 3-Pin SOT-23 BSN20BKR

Nexperia BSN20BKR N-Channel MOSFET, rated for 330 mA continuous drain current and 60 V maximum drain-source voltage, operates in an enhancement mode and uses a 3-Pin SOT-23 package suitable for surface mount technology.

This semiconductor device offers reliable switching and amplification performance with a maximum power dissipation of 1.67 W, supporting moderate power electronic circuits in industrial, electronic, and power management applications.

The device features a low gate charge of 0.49 nC at Vgs, facilitating efficient high-speed switching and reduced power loss during transitions. Operating temperature ranges from -55°C to 150°C, making it adaptable for demanding thermal environments.

The maximum drain-source resistance is 2.8 Ω, contributing to overall minimized conduction loss and thermal dissipation. Compact dimensions of 3 mm length, 1.4 mm width, and 1 mm height simplify PCB footprint and facilitate high-density circuit layouts.

Typical forward voltage is 1.2 V supporting efficient operation and switching in electronic circuits.

This Nexperia MOSFET is widely used in semiconductor discrete component applications including power management, signal amplification, and switching devices in industrial and consumer electronic assemblies.

Features a compact 3-Pin SOT-23 surface mount package for efficient PCB integration. Enhancement type N-Channel providing reliable switching control. Rated for a maximum continuous drain current of 330 mA and max drain-source voltage of 60 V.

Low gate charge ensures efficient switching and reduced transition losses. Wide operating temperature range supports use in diverse environmental conditions. Typical forward voltage of 1.2 V facilitates efficient operation.

Maximum power dissipation of 1.67 W supports moderate power applications. Durable construction with surface mount design for compact electronics.

Choose this Nexperia BSN20BKR MOSFET for dependable discrete semiconductor solutions in industrial, laboratory, and electronic manufacturing applications. Browse the extensive range of Nexperia semiconductors on EnvMart for complementary components.
