Hirose FPC Connector 0.5 mm Pitch 14 Way Straight Female ZIF Solder FH34SRJ
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 50V ac |
| Brand | Hirose |
| Orientation | Straight |
| Current | 500mA |
| Model | FH34SRJ |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer, Polyamide |
| Contact Material | Phosphor Bronze |
| Series | FH34SRJ |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Sub Type | FPC |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 0.5mm |
| Contact Plating | Nickel, Gold |
| Number of Contacts | 14 |
| Contact Gender | Female |
| Connector Gender | Female |
| Insertion Force | ZIF |
| Contact Position | Top, Bottom |
Key Features
- Low profile height of 1.00 mm for compact electronic designs.
- Back-flip rotating actuator provides easy zero insertion force (ZIF) insertion.
- High retention force secures FPC/FFC connection firmly.
- Top and bottom contact positions add design flexibility.
- Housing made from liquid crystal polymer and polyamide materials for durability.
- Contact plating includes nickel and gold for corrosion resistance.
- Operates at voltage rating of 50V AC and current of 500mA.
- Wide operating temperature range from -55°C to 85°C.
Product Description
Hirose FH34SRJ FPC Connector 0.5 mm Pitch, Model FH34SRJ, is a high-quality 14 way straight female FPC connector designed for surface mount technology with solder termination. It features a low profile height of 1.00 mm above the PCB, making it suitable for use in applications requiring compact electronic assembly.
The connector includes a back-flip rotating actuator enabling zero insertion force (ZIF) for easy FPC/FFC cable insertion and a tactile click confirms firm locking when closed. The high retention force ensures durable electrical and mechanical connection. The connector has contacts on both top and bottom sides to provide flexible design options.
The housing is constructed from liquid crystal polymer and polyamide to provide mechanical strength and chemical resistance. Contacts are made of phosphor bronze with nickel and gold plating to prevent corrosion and maintain conductivity.
This product complies with halogen free standards according to IEC61249-2-21, making it environmentally safer for use in electronics manufacturing. It operates reliably under temperature ranges from -55°C to 85°C, suitable for mobile phones, notebook PCs, DVD players, and LCD monitors.
The flat upper surface also allows for vacuum pick-up during automated PCB assembly. The bottom is solid with no exposed contacts, allowing the connector to be mounted over conductive PCB traces without risk of shorts.
Low profile height of 1.00 mm for compact designs. Back-flip rotating actuator for easy ZIF insertion. High retention force for secure connections. Top and bottom contact positions for flexibility. Durable housing materials: liquid crystal polymer and polyamide.
Nickel and gold contact plating for corrosion resistance. Rated for 50 V AC voltage and 500 mA current. Wide operating temperature range -55°C to 85°C. Halogen free per IEC61249-2-21 compliance.
This FPC Connector is ideal in industrial, consumer electronics, telecommunications, and manufacturing applications where reliable, low profile interconnection is required. Explore the quality range of Hirose connectors and related electronic components on EnvMart for robust and versatile solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Hirose FH34SRJ connector operates at a voltage rating of 50V AC.
This model has a current capacity of 500mA.
The pitch size of the FH34SRJ connector is 0.5 mm.
The housing is made from liquid crystal polymer and polyamide materials.
This connector uses solder termination.
It operates reliably within a temperature range of -55°C to 85°C.
The connector features 14 contacts.
This model utilizes a zero insertion force (ZIF) design for easy cable insertion.
The contacts are plated with nickel and gold for corrosion resistance.
Yes, it complies with halogen-free standards according to IEC61249-2-21.
The orientation of this connector is straight.
This connector is suitable for applications in industrial, consumer electronics, telecommunications, and manufacturing.
