TDK Single Phase Chassis Mount EMC Filter B84113H 36A 250V AC/DC 50Hz, 60Hz Screw Termination B84113H0000M136

Free Delivery in India | Lowest Global Shipping Charges

TDK Single Phase Chassis Mount EMC Filter B84113H 36A 250V AC/DC 50Hz, 60Hz Screw Termination B84113H0000M136



Category Power Line Filters Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	53mm
Length	133mm
Model	B84113H0000M136
Depth	58mm
Mount Type	Chassis Mount
Operating Frequency	50, 60Hz
Series	B84113H
Maximum Operating Temperature	100°C
Number Of Stages	2
Capacitance	2μF
Minimum Operating Temperature	-25°C
Maximum Current	36A
Number of Phases	1
Leakage Current	0mA
Maximum Voltage	250V ac/dc
Inductance	4mH
Standards/Approvals	UL 1283
Termination Style	Screw

Key Features

Compact chassis mount design for easy installation.
Equipped with screw termination style for secure connections.
2-stage filter with 2μF capacitance and 4mH inductance.
Operates reliably between -25°C and 100°C temperatures.
Zero leakage current ensuring high efficiency and safety.
Standards compliant with UL 1283 certification.
Primarily used in switched mode power supplies for telecom and data systems.
Polyurethane potting with UL 94 V-0 rating for enhanced durability.

Product Description

TDK B84113H0000M136 is a single phase chassis mount EMC filter designed for electronic applications requiring robust noise suppression and high current handling. It supports a maximum current of 36 amperes and rated voltage of 250 volts AC/DC, making it suitable for industrial and telecommunications equipment.

The filter operates effectively at frequencies of 50Hz and 60Hz and consists of two stages, providing superior electromagnetic interference reduction. The capacitance value of 2 microfarads and inductance of 4 millihenries contribute to its noise filtering capabilities while maintaining zero leakage current, ensuring system safety and compliance.

Constructed with a compact chassis mount design, this EMC filter uses screw termination style connections for reliable and secure electrical contacts. Its polyurethane potting meets UL 94 V-0 flammability standards, enhancing operational safety and moisture resistance.

The device functions reliably across a wide temperature range from -25°C to 100°C, making it adaptable to various industrial environments. Its dimensions measure 133 mm in length, 58 mm in depth, and 53 mm in height, allowing efficient space usage in equipment setups.

This EMC filter is widely used in switched mode power supplies for telecom and data systems to mitigate electromagnetic noise and maintain signal integrity. It meets UL 1283 approvals and features threaded M5 stud terminals that support filter currents up to 36A.

Compact and easy to install chassis mount design. High insertion loss for efficient EMI suppression. Durable polyurethane potting with UL 94 V-0 rating. Supports 36A maximum current with screw-type terminations. Certified to UL 1283 standard and compliant with ENEC10, UL, and cUL approvals.

Ideal for industrial, telecommunications, and data communication equipment, this EMC filter ensures robust performance and compliance with international safety standards. Explore the TDK range at EnvMart for reliable EMI filtering solutions.
