TDK Shielded Wirewound Surface Mount Inductor, Ferrite Core, 3.3 μH ±20/±30 % Inductance, 4.95 A Idc, 6045 VLS6045EX-3R3N
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 6mm |
| Model | VLS6045EX-3R3N |
| Depth | 6mm |
| Packaging | Reel |
| Series | VLS-EX |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 3.3μH |
| Standards/Approvals | RoHS |
| Package/Case | 6045 |
| Maximum DC Current | 4.95A |
| Maximum DC Resistance | 23mΩ |
| Inductance Tolerance | ±20/±30 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Magnetically shielded for enhanced power circuit performance.
- Compact 6045 package size with 6 mm length, 4.5 mm height, and 6 mm depth.
- Constructed with ferrite core and wirewound inductor construction for high reliability.
- Operating temperature range from -40°C to 105°C ensuring durability.
- Compliant with RoHS standards for environmental safety.
- Surface mount termination style compatible with high-density PCB mounting.
- Offers low DC resistance of 23 mΩ for efficient power handling.
- Packaged in reels to support automated assembly processes.
Product Description
TDK VLS6045EX-3R3N is a shielded wirewound surface mount inductor featuring a ferrite core that offers an inductance of 3.3 μH with tolerance ±20/±30 %. This inductor supports a maximum DC current of 4.95 A, making it suitable for demanding power circuit applications.
The 6045 package dimensions measure 6 mm in length, 4.5 mm in height, and 6 mm in depth, optimized for high-density surface mount technology (SMT) use. The unit is magnetically shielded with a ferrite magnetic material that ensures reduced electromagnetic interference, delivering high performance and reliability.
The device operates across a wide temperature range from -40°C up to 105°C and complies fully with RoHS environmental standards. Its low maximum DC resistance of 23 mΩ contributes to efficient energy transfer with minimal losses.
Packaged on reels, the VLS6045EX-3R3N supports automated PCB assembly lines for efficient manufacturing processes. The surface mount termination style facilitates compact, space-saving layouts in modern electronic devices.
This inductor series is ideal for use in TVs, game devices, set-top boxes (STBs), and audiovisual equipment, providing stable and consistent inductance performance in compact form factors.
Magnetically shielded wirewound ferrite core construction for power circuits. Compact 6045 package optimized for surface mount assembly. Supports high current carrying capacity of 4.95 A DC. Wide operating temperature range from -40°C to 105°C.
RoHS compliant ensuring eco-friendly manufacturing. Low DC resistance of 23 mΩ for efficient performance. Packaged in reels for convenience in automated manufacturing. Termination style suitable for surface mounting on PCBs.
Suitable for industrial and consumer electronics manufacturing, this Surface Mount Inductor provides reliable filtering and energy storage capabilities. Explore EnvMart’s extensive range of electronic components and inductors for your power management and signal processing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 3.3 μH with a tolerance of ±20/±30%.
It supports a maximum DC current of 4.95 A, making it suitable for demanding power circuit applications.
The dimensions of the 6045 package are 6 mm in length, 4.5 mm in height, and 6 mm in depth.
The operating temperature range is from -40°C to 105°C, ensuring its performance in various environments.
It is constructed with a ferrite core, which contributes to its performance and reliability.
Yes, it is compliant with RoHS standards, ensuring environmental safety during manufacturing.
The maximum DC resistance is 23 mΩ, which aids in efficient power handling.
It features a surface mount termination style, suitable for high-density PCB mounting.
It is packaged in reels, which supports automated assembly processes in manufacturing.
This model is suitable for use in TVs, game devices, set-top boxes (STBs), and audiovisual equipment.
It is a wirewound inductor, which provides high reliability for power circuit applications.
This inductor belongs to the VLS-EX series, which is designed for surface mount applications.
