Wurth Elektronik WR-FPC 0.5 mm Pitch 6 Way Horizontal Female FPC Connector ZIF Bottom Contact 687106149022
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 50, 50V ac |
| Brand | Wurth Elektronik |
| Orientation | Horizontal |
| Current | 500mA |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Phosphor Bronze |
| Series | WR-FPC |
| Termination Type | ZIF Bottom Contact |
| Maximum Operating Temperature | 105°C |
| Sub Type | FPC |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 0.5mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector Gender | Female |
| Insertion Force | ZIF |
| Contact Position | Bottom |
Key Features
- This FPC connector features a zero insertion force (ZIF) bottom contact termination for minimal cable wear.
- Constructed with phosphor bronze contacts plated with tin over nickel for reliable conductivity.
- The polyamide housing provides excellent mechanical stability and durability.
- Operates within a temperature range of -40°C to 105°C suitable for various environments.
- Designed with a horizontal orientation and flip-lock hinged actuator ensuring secure cable retention.
- Rated for 500mA current and 50V AC voltage for low-power electronic applications.
- This connector supports a single row configuration with 6 contacts ensuring compact high-density connections.
Product Description
Wurth Elektronik model 687106149022 is a high-quality FPC connector featuring a 0.5 mm pitch and 6 way horizontal female configuration with zero insertion force (ZIF) bottom contacts. It incorporates a hinged flip-lock actuator that secures the flexible printed circuit (FPC) cable in place, providing a secure and reliable electrical connection for miniaturized electronic assemblies.
The connector uses phosphor bronze contact material with tin over nickel plating to ensure excellent electrical performance and corrosion resistance. Its polyamide housing offers a lightweight and durable solution designed for surface mount technology (SMT) applications. With a low profile design, this connector meets the increasing demands for high-density electronic packaging and space-saving solutions.
Operating reliably between -40°C to 105°C and handling currents up to 500mA at 50V AC, it is suitable for varied industrial, electronic, and manufacturing environments. The ZIF termination type reduces cable damage during multiple insertions, making it ideal for applications requiring frequent assembly and disassembly.
Typical industrial use cases include compact display connectors, keyboard interface solutions, and general FPC cable terminations in electronics manufacturing, industrial control systems, and telecommunications equipment.
This connector features a horizontal orientation with a flip-lock hinged actuator securing the connection. The 6 contact single-row design facilitates secure cable connection in space-constrained applications. The polyamide housing ensures mechanical strength and thermal stability during operation.
The contact material is phosphor bronze plated with tin over nickel for optimal conductivity and corrosion resistance. Rated for 500mA and 50V AC, suitable for various low-voltage electronic circuits.
Wurth Elektronik products are engineered for reliability and performance in demanding industrial and electronic manufacturing sectors. Explore more FPC Connectors and electronic component solutions from Wurth Elektronik on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this FPC connector is 0.5 mm.
This connector features 6 contacts in a single row configuration.
The maximum operating temperature for this connector is 105°C.
It is rated for a current of 500mA and a voltage of 50V AC.
This connector uses a zero insertion force (ZIF) bottom contact termination type.
The housing of this connector is made from polyamide, providing mechanical stability.
This model has a horizontal orientation.
This connector is suitable for applications such as compact display connectors, keyboard interfaces, and general FPC cable terminations in electronics manufacturing.
The contact material is phosphor bronze, plated with tin over nickel for reliable conductivity.
The minimum operating temperature for this connector is -40°C.
This connector is designed for surface mount technology (SMT) applications.
The flip-lock actuator secures the flexible printed circuit (FPC) cable in place, ensuring a reliable electrical connection.
