TDK VLCF 5020 Shielded Wirewound Surface Mount Inductor with Ferrite Core 15µH ±20% 1.2A Idc VLCF5020T-150MR90-1

TDK VLCF5020T-150MR90-1 is a professional series shielded wirewound surface mount inductor featuring a ferrite core optimized for power circuit applications. It delivers an inductance of 15µH with a tolerance of ±20%, capable of handling a maximum DC current of 1.2A. The device is designed in a compact 5020 package measuring 5mm in length, 5mm in depth, and 2mm in height, making it suitable for high-density surface mount PCB layouts.

This inductor incorporates a high magnetic shield structure which reduces electromagnetic interference and enhances circuit performance. Its construction includes a ferrite core and shielded winding to ensure stability across the operating temperature range of -40°C to 105°C.

With a maximum DC resistance of 350mΩ, this component is designed for efficiency and reliability in power source circuits such as those found in mobile devices including hard disk drives (HDDs), digital video cameras (DVCs), digital still cameras (DSCs), and LCD displays. It supports robust operation in DC to DC converter lines with generic use in portable electronics.

The VLCF5020T-150MR90-1 unit comes tape and reel packaged, facilitating automated insertion in production environments. RoHS compliance confirms adherence to environmental and safety standards.

TDK’s Non-Standard SMT Inductor range is engineered to deliver excellent magnetic shielding and performance in compact form factors, making it a trusted choice for industrial, mobile, and commercial electronic manufacturing.

Constructed with high magnetic shield for interference reduction. Magnetically shielded wire wound choke for enhanced performance. Compact 5020 package size with 5mm length and 2mm height. Supports 1.2A maximum DC current with 350mΩ maximum DC resistance.

Operating temperature range from -40°C to 105°C. Ferrite core material provides stable inductance and durability. Designed for surface mount applications with solder termination. RoHS compliant ensuring environmental standards.

Ideal for power source inductors in mobile devices and DC-DC converters. Packaged on tape and reel for automated assembly processes. Explore the TDK VLCF series and other electronics components on EnvMart for high-quality standards and industry-approved parts for your manufacturing and development needs.
