onsemi Operational Amplifier Dual Channel 8-Pin SOIC 3V to 36V 24 MHz GBP High Slew Rate NCV33272ADR2G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.5mm |
| Length | 5mm |
| Model | NCV33272ADR2G |
| Width | 4mm |
| Mount Type | Surface |
| Low Noise | 18 nV/ (square root Hz) @ 1 kHz |
| Series | NCV33272 |
| Output Current | 37mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 36V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 24MHz |
| Input Bias Current | 650 nA |
| Vos - Input Offset Voltage | 1 mV |
| Slew Rate | 10V/μs |
| Input Offset Current | 65 nA |
| Low input bias current | 300 nA |
| Low Input Offset Current | 3.0 nA |
| High Input Resistance | 16 MΩ |
| High Gain Bandwidth Product | 24 MHz @ 100 kHz |
Key Features
- High slew rate of 10 V/μs ensures fast response in signal amplification applications.
- Wide supply voltage range from 3 V to 36 V allows flexible power input options.
- Low input offset voltage of 1 mV supports precision amplification.
- Two channels provide dual operational amplifier capability in a single package.
- Compact SOIC package with 8 pins facilitates surface mount PCB integration.
- Operating temperature range from -40°C to 125°C ensures reliability in diverse environmental conditions.
- Compliance with RoHS standards maintains environmental safety and regulatory compliance.
- Automotive grade with AEC-Q100 certification ensures robust performance in automotive applications.
Product Description
onsemi NCV33272ADR2G is a dual channel operational amplifier designed for high performance in amplification and signal processing tasks. Featuring a 24 MHz gain bandwidth product and a high slew rate of 10 V/μs, this device offers rapid and precise signal amplification in a compact 8-pin SOIC surface mount package.
This operational amplifier supports supply voltages ranging from 3 V to 36 V, providing versatility for various industrial and automotive power systems. Its low input offset voltage of 1 mV and low noise floor of 18 nV/√Hz at 1 kHz enable accurate and low-distortion amplification, suitable for high-fidelity audio, instrumentation, and control applications.
The device is qualified under AEC-Q100 automotive standards, ensuring durability and reliability in automotive electronics. It operates reliably within a wide temperature range of -40°C to 125°C, making it suitable for harsh environments encountered in industrial and automotive sectors.
The robust output stage delivers a maximum output current of 37 mA, enabling it to drive moderate loads effectively. Additionally, the amplifier uses patented Zip-R-Trim technology for input offset voltage reduction, improving overall accuracy and stability.
High slew rate of 10 V/μs for fast signal transition. Wide supply voltage of 3 V to 36 V for flexible power usage. Low input offset voltage trimmed to 1 mV for precision. Dual channel architecture supports multiple simultaneous amplification tasks.
Compact surface mount SOIC 8-pin package simplifies PCB design. Meets RoHS environmental compliance standards. Automotive certified with AEC-Q100 standard for harsh conditions. Low noise operation ideal for sensitive electronic circuits.
Capable output current of 37 mA to drive loads efficiently. Operating temperature spans -40°C to 125°C for industrial reliability.
This operational amplifier is suited for industrial machines, automotive systems, instrumentation, and high-speed analog signal processing applications. It is widely used in design and manufacturing of electronic control units, sensor interfaces, audio amplification, and power management circuits. Enabling engineers to achieve precise, reliable, and efficient amplification, this onsemi NCV33272ADR2G is an optimal component for advanced electronic designs.
Explore more Operational Amplifiers and semiconductor devices in the onsemi product range at EnvMart for diverse electrical and electronics project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 24 MHz.
It supports a supply voltage range from 3 V to 36 V.
The operational amplifier can deliver a maximum output current of 37 mA.
The input offset voltage is trimmed to 1 mV, which supports precision amplification.
It operates reliably within a temperature range of -40°C to 125°C.
This model features two channels, providing dual operational amplifier capability in a single package.
It comes in a compact SOIC package with 8 pins, suitable for surface mount integration.
The slew rate is 10 V/μs, ensuring fast response in signal amplification applications.
It has a low noise floor of 18 nV/√Hz at 1 kHz, making it suitable for sensitive applications.
Yes, it complies with RoHS standards and is certified under AEC-Q100 for automotive applications.
The input bias current is 650 nA, which is relatively low for operational amplifiers.
It is suitable for industrial machines, automotive systems, instrumentation, and high-speed analog signal processing applications.
