Nexperia High Voltage PNP Bipolar Transistor PBHV9040T,215 -250 mA, -400 V, 3-Pin SOT-23 PBHV9040T,215

The Nexperia PBHV9040T,215 is a high voltage PNP bipolar transistor optimized for reliable performance in demanding electronic switching and amplification applications. This transistor supports a maximum DC collector current of -250 mA and a collector emitter voltage of -400 V, making it suitable for high voltage circuits in industrial and electronic equipment.

Packaged in a compact 3-pin SOT-23 surface mount form factor, the PBHV9040T,215 offers ease of integration into automated assembly processes and dense circuit boards.

This single transistor configuration features PNP polarity, supporting negative polarity high voltage operations with robust tolerance to collector base voltage up to -500 V. It dissipates up to 300 mW of power, allowing it to be used in moderate power applications efficiently.

Operating temperature range spans from -55°C to 150°C, ensuring reliable operation under harsh environmental conditions common in industrial, telecommunications, automotive, and power management systems.

The transistor's minimum DC current gain of 100 offers solid gain characteristics for reliable switching and amplification tasks. Additionally, the maximum transition frequency of 55 MHz supports high-speed switching applications.

Its compact size with dimensions 3 mm length, 1.4 mm width, and 1.1 mm height supports space-saving PCB designs and lightweight electronic assemblies in industries such as consumer electronics, power supply units, and other embedded systems.

This transistor is housed in a compact 3-pin SOT-23 surface mount package. Features a single transistor configuration with PNP polarity. Maximum power dissipation is 300 mW allowing moderate power handling. Designed to operate from -55°C to 150°C for wide temperature tolerance.

Minimum DC current gain (hFE) of 100 ensures effective amplification. Maximum collector base voltage rating of -500 V for high voltage circuits. Maximum transition frequency of 55 MHz for switching and amplification speed.

Compact dimensions of 3 x 1.4 x 1.1 mm support dense PCB layouts.

This transistor is a versatile component suitable for use in industrial electronics, power management, telecommunications, automotive electronics, and other sectors requiring robust, high voltage PNP bipolar transistors. Explore more advanced semiconductor components and electronic parts in the EnvMart Bipolar Transistors category for your design and manufacturing needs.
