onsemi 8-Channel Non-Inverting 3 State Buffer, 20-Pin TSSOP MC74LCX541DTG
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.05mm |
| Operating Voltage Range | 2.0 to 3.6V |
| Length | 6.6mm |
| Model | MC74LCX541DTG |
| Mount Type | Surface |
| Output type | 3 State |
| Series | MC74LCX541 |
| Input Type | TTL |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Polarity | Non-Inverting |
| Number Of Channels | 8 |
| Pin Count | 20 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 3.6V |
| Logic Family | LCX |
| Logic Function | Buffer |
| Minimum Supply Voltage | 2V |
| Maximum High Level Output Current | -24mA |
| Maximum Propagation Delay Time @ CL | 7.5ns |
| Supply Current | 10μA |
| Maximum Low Level Output Current | 24mA |
Key Features
- Operates with a voltage range of 2.0 to 3.6 volts, suitable for low voltage CMOS logic applications.
- Features TTL input type with non-inverting output polarity.
- Provides 3-state output functionality enabling high impedance state for bus-oriented applications.
- Maximum propagation delay time of 7.5 nanoseconds allows for high-speed signal processing.
- Compact 20-pin TSSOP surface mount package with height of 1.05 mm and length of 6.6 mm.
- Meets AEC-Q100 automotive standard, ensuring reliability in harsh environments.
- Supply current is low at 10 microamperes, optimizing power consumption.
- Operating temperature ranges from -40°C to 85°C for industrial and automotive use.
Product Description
onsemi MC74LCX541DTG is a specialized 8-channel non-inverting 3 state buffer IC housed in a compact 20-pin TSSOP package. It is designed to provide reliable digital logic buffering with a low-voltage CMOS technology operation range between 2.0 and 3.6 volts, supporting advanced high-speed switching capabilities.
This device utilizes TTL input logic with non-inverting outputs that can enter a high impedance 3-state mode, making it ideal for bus-oriented applications and complex logic circuit designs. The maximum propagation delay time is 7.5 nanoseconds at typical load conditions, ensuring fast signal processing.
The MC74LCX541DTG features low supply current consumption of approximately 10 microamperes, maintaining energy efficiency in designs. It supports an operating temperature range from -40°C to 85°C, making it suitable for industrial and automotive electronics. The component also complies with the automotive AEC-Q100 qualification standard, guaranteeing robustness and reliability under demanding conditions.
Its 20-pin TSSOP surface mount package measures 6.6 mm in length and 1.05 mm in height, allowing for compact PCB layouts. Output currents of -24 mA (high level) and 24 mA (low level) provide strong signal drive for connected components.
Operates at 2.0 to 3.6 V supply voltage range. 8 buffered channels with 3-state output capability. Low power consumption with 10 µA typical supply current. Meets automotive-grade AEC-Q100 standard. Compact 20-pin TSSOP packaging suitable for surface mounting.
TTL inputs and non-inverting output polarity. Robust operation between -40°C and 85°C ambient temperature. Suitable for industrial, automotive, and consumer electronics applications. Fast propagation delay of 7.5 ns enables high-speed logic control.
Strong output current drive supports various digital signals.
This buffer IC is widely used in electronic component assemblies for power and signal conditioning in automotive, industrial automation, manufacturing, and embedded systems. It plays a critical role in maintaining signal integrity in complex logic circuits requiring multiple buffered outputs with tri-state control.
Explore the category of Semiconductor Logic ICs on EnvMart for additional integrated circuits, including buffers, drivers, and logic gates from leading manufacturers such as onsemi.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates within a voltage range of 2.0 to 3.6 volts, making it suitable for low voltage CMOS logic applications.
The MC74LCX541DTG features 8 buffered channels, allowing for multiple signal processing tasks.
The maximum propagation delay time is 7.5 nanoseconds, enabling high-speed signal processing capabilities.
It utilizes TTL input type, which is compatible with various digital logic levels.
This unit provides a 3-state output functionality, allowing it to enter a high impedance state for bus-oriented applications.
The supply current is low at approximately 10 microamperes, optimizing power consumption in applications.
The package measures 6.6 mm in length and 1.05 mm in height, suitable for compact PCB layouts.
It operates effectively within a temperature range of -40°C to 85°C, making it suitable for industrial and automotive applications.
Yes, it meets the AEC-Q100 automotive standard, ensuring reliability in harsh environments.
The maximum high level output current is -24 mA, while the low level output current is 24 mA, providing strong signal drive.
It supports surface mounting, which is ideal for modern electronic circuit designs.
This buffer IC belongs to the LCX logic family, which is known for low voltage applications.
