Wurth Elektronik WE-PD Shielded Wirewound Surface Mount Inductor 6.8 μH ±20% 2.5 A IDC 7447789006
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 3.2mm |
| Length | 7.3mm |
| Depth | 7.3mm |
| Packaging | Tape & Reel |
| Series | WE-PD |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Inductance | 6.8μH |
| Standards/Approvals | IEC 62024-2-2020, JEDEC JS709B, REACH, RoHS |
| Package/Case | 7332 |
| Maximum DC Current | 2.5A |
| Maximum DC Resistance | 44mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 26MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Magnetically shielded wire wound design ensures low leakage field.
- Rated maximum DC current of 2.5 A for high current applications.
- Inductance tolerance of ±20% suitable for consistent performance.
- Compact 7332 package with dimensions 7.3 mm length and 3.2 mm height.
- Compatible with tape and reel packaging for automated assembly.
- Meets automotive standard AEC-Q200 for reliability.
- Surface mount termination style for PCB assembly.
- Maximum self resonant frequency of 26 MHz enhances efficiency in switching power supplies.
Product Description
Wurth Elektronik model 7447789006 is a magnetically shielded wirewound surface mount inductor from the WE-PD series designed for high reliability in industrial, automotive, and electronic applications. Its 6.8 μH inductance with ±20% tolerance provides stable frequency control and energy storage capabilities in switching regulators and DC-DC converters.
The 7332 package measures 7.3 mm in length and 3.2 mm in height, constructed with a wirewound design and features magnetic shielding to minimize electromagnetic interference, making it suitable for high precision circuit environments. It supports a maximum DC current of 2.5 A and has a low maximum DC resistance of 44 mΩ, ensuring efficient power handling and reduced losses.
This inductor complies with IEC 62024-2-2020, JEDEC JS709B, REACH, and RoHS standards and is certified to the automotive AEC-Q200 standard, affirming its suitability for automotive electronics requiring durability under thermal and mechanical stress.
Designed for surface mount technology with tape and reel packaging, it enables efficient and automated PCB assembly processes. Its maximum operating temperature is 125°C, and it withstands a minimum temperature of -40°C, making it versatile for diverse operating environments.
Magnetic shielding for reduced leakage and improved EMI performance. Used in switching regulators, high-efficiency DC-DC converters, and graphic card power supplies. Plastic moulded construction suitable for shock and vibration resistant applications.
Compact surface mount package eases integration into dense PCB layouts. High self-resonant frequency of 26 MHz enhances performance at high switching frequencies. Offers reliable and consistent inductance for power electronics design.
This Wurth Elektronik WE-PD series inductor caters to demanding industrial electronics, automotive systems, and commercial electronic products requiring compact, reliable inductors with low EMI and high current capacity. Explore more inductors and electronic components within this category for specialized applications at EnvMart.
Explore more products in our Surface Mount Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 6.8 μH with an inductance tolerance of ±20%.
It has a maximum DC current rating of 2.5 A, making it suitable for high current applications.
The dimensions of the 7332 package are 7.3 mm in length and 3.2 mm in height.
The maximum self-resonant frequency of this inductor is 26 MHz, which enhances its efficiency in switching power supplies.
This inductor features a surface mount termination style, suitable for PCB assembly.
The inductor can operate at a maximum temperature of 125°C and a minimum temperature of -40°C, allowing it to function in diverse environments.
It complies with IEC 62024-2-2020, JEDEC JS709B, REACH, RoHS, and is certified to the automotive standard AEC-Q200.
The maximum DC resistance is 44 mΩ, which contributes to efficient power handling and reduced losses.
This model is constructed using a wirewound design, which helps in minimizing electromagnetic interference.
It is packaged in tape and reel format, facilitating automated assembly processes.
This inductor is suitable for use in switching regulators, high-efficiency DC-DC converters, and graphic card power supplies.
This inductor belongs to the WE-PD series, designed for high reliability in various electronic applications.
