| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1mm |
| Length | 2.7mm |
| Model | MM3Z12VST1G |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 200mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 100nA |
| Nominal Zener Voltage Vz | 12V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 25Ω |
| Typical Voltage Temperature Coefficient | 6mV/K |
| Surface Mount case | SOD-323 (SC-76) |
| Nexperia 1, 12 V Zener Diode, Single 300 mW 2 % Surface 2-Pin SOD-323Brand | Nexperia |
The onsemi MM3Z12VST1G is a 12 V Zener diode designed for voltage regulation in electronic circuits. It is a single-element device housed in a compact surface mount SOD-323 (SC-76) package, making it suitable for applications requiring space-saving semiconductor components.
This Zener diode offers a maximum power dissipation of 200 mW and operates reliably within a temperature range from -65°C up to 150°C, providing robust performance under various environmental conditions.
It features a tight voltage tolerance of ±2%, ensuring precise voltage regulation. The device carries a nominal Zener voltage of 12 volts and a test current rating of 5 mA, combined with a maximum Zener impedance of 25 ohms to optimize circuit stability.
The maximum reverse leakage current is limited to 100 nA, promoting minimal leakage and energy efficiency. Compliant with RoHS standards, this diode supports environmentally responsible manufacturing and usage.
With a height of 1 mm and a length of 2.7 mm, it supports compact PCB designs typically required in modern electronics. The typical voltage temperature coefficient is 6 mV/K, indicating stable voltage characteristics under thermal variations.
Designed for voltage regulation applications. 200 mW maximum power dissipation. Surface mount SOD-323 package for compactness. Wide operating temperature range: -65°C to 150°C. 2 % voltage tolerance for precision control.
Low reverse leakage current for energy efficiency. RoHS compliant for environmental safety. Nominal Zener voltage of 12 V at 5 mA test current. Typical voltage temperature coefficient of 6 mV/K. Package dimensions: 1 mm height, 2.7 mm length.
This Zener diode is suitable for use in industrial electronics, power supplies, communication devices, and other applications requiring stable voltage regulation. It is well suited for surface mount technology (SMT) assembly on printed circuit boards, supporting efficient manufacturing processes.
