Samtec MB1 Series Straight Edge Connector Female, Surface Mount, 20 Contacts, 1 mm Pitch, 1 Row, Solder MB1-120-01-L-S-01-SL
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Current | 2.2A |
| Model | MB1-120-01-L-S-01-SL |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy |
| Series | MB1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 20 |
| Contact Gender | Female |
| Connector Gender | Female |
| Card Type | Edge |
| Card Thickness | 0.8mm |
| Insulator Material | Black LCP |
| MB1-1xx-01-L-S-02-SL | take 1.6 mm thick cards |
| MB1-1xx-01-L-S-01-SL | take 0.8 mm thick cards |
Key Features
- The connector supports a current rating of 2.2 amps for reliable power transmission.
- It is designed to accommodate 0.8 mm thick cards, providing precise fitment.
- Constructed with beryllium copper alloy contacts plated in gold over nickel for excellent conductivity and corrosion resistance.
- The housing is made of durable liquid crystal polymer with black LCP insulator material for thermal stability.
- Operating temperature range extends from -55°C to 125°C ensuring performance under harsh conditions.
- Termination is by solder type, ensuring secure and lasting PCB connections.
- Compact 1 mm pitch and 1 row layout ideal for mini edge card sockets in electronic assemblies.
- Complies with standard edge connector requirements but has no specific standards or approvals listed.
Product Description
Samtec MB1-120-01-L-S-01-SL is a premium MB1 Series straight edge connector featuring 20 female contacts in a single row, with 1 mm pitch and surface mount design. It is engineered for the reliable connection of mini edge cards with a thickness of 0.8 mm, making it suitable for compact electronic assemblies and devices.
The connector's contacts are crafted from a high-grade beryllium copper alloy, plated with gold over nickel to ensure excellent electrical conductivity and resistant to corrosion. The housing utilizes a black liquid crystal polymer (LCP), offering high thermal stability and mechanical robustness.
This edge connector supports a continuous current of 2.2 amps and operates efficiently in temperatures ranging from -55°C to 125°C, making it well suited for demanding industrial, electronic, and manufacturing applications.
The solder termination type enables secure and durable mounting on printed circuit boards, facilitating efficient manufacturing processes. The connector is ideal for use in electronic components, power connectors, and edge connector applications requiring miniature, high-performance connectivity.
The connector supports a current rating of 2.2 amps for reliable power transmission. It is designed to accommodate 0.8 mm thick cards, providing precise fitment. Constructed with beryllium copper alloy contacts plated in gold over nickel for excellent conductivity and corrosion resistance.
The housing is made of durable liquid crystal polymer with black LCP insulator material for thermal stability. Operating temperature range extends from -55°C to 125°C ensuring performance under harsh conditions. Termination is by solder type, ensuring secure and lasting PCB connections.
Compact 1 mm pitch and 1 row layout ideal for mini edge card sockets in electronic assemblies. Complies with standard edge connector requirements but has no specific standards or approvals listed.
This connector is commonly used in electronic manufacturing, industrial automation, and power systems where reliable, compact edge connector solutions are essential. Its compatibility with 0.8 mm card thickness and robust material construction make it a versatile choice for demanding applications.
Explore a wide range of Edge Connectors and related electronic components on EnvMart for your manufacturing and repair needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector supports a current rating of 2.2 amps, ensuring reliable power transmission.
This model features a 1 mm pitch and has 20 female contacts in a single row.
It utilizes a solder termination type, which ensures secure and durable mounting on printed circuit boards.
The operating temperature range extends from -55°C to 125°C, making it suitable for harsh conditions.
The contacts are made from beryllium copper alloy, plated with gold over nickel, while the housing is constructed from liquid crystal polymer (LCP).
It is designed to accommodate cards with a thickness of 0.8 mm, providing precise fitment.
The housing is made of durable liquid crystal polymer (LCP), which offers thermal stability.
This connector has a single row design, making it compact and suitable for mini edge card sockets.
Yes, it is commonly used in electronic manufacturing, industrial automation, and power systems due to its reliable connectivity.
It supports edge cards, specifically designed for mini edge card applications.
The connector is manufactured in India.
While it complies with standard edge connector requirements, there are no specific standards or approvals listed for this model.
