onsemi LM317LBDR2G Adjustable Linear Voltage Regulator 1.2 - 37V 1.5A 8-Pin SOIC LM317LBDR2G
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Regulators onsemi LM317LBDR2G, Voltage Regulator 37V SOIC 8-Pin RS Stock No |
| Brand | onsemi |
| Height | 1.5mm |
| Length | 5mm |
| Model | LM317LBDR2G |
| Width | 4mm |
| Mount Type | Surface |
| Series | LM317 |
| Output Current | 1.5 A |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Polarity | Positive |
| Maximum Input Voltage | 37V |
| Quiescent Current | 3.5mA |
| Output Voltage Range | 1.25 V to 37 V |
| Minimum Input Voltage | 1.2V |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
Key Features
- The device operates with a quiescent current of 3.5mA providing efficient power management.
- Built to withstand maximum operating temperature of 125°C and input voltages up to 37V.
- Incorporates short circuit current limiting, thermal shutdown, and safe-area compensation for reliable operation.
- Supports floating operation for high-voltage applications in electronics and industrial control systems.
- Automotive grade compliant to AEC-Q100 standards ensuring durability in harsh environments.
- Ideal for on-card regulation and programmable output applications requiring precise voltage and current control.
- Positive polarity linear voltage regulator suitable for numerous electronic component designs.
- Offers excellent thermal performance and stability across its operating range.
Product Description
onsemi LM317LBDR2G is an adjustable linear voltage regulator designed for versatile power management applications. It features an 8-pin SOIC surface mount package with compact dimensions measuring 5mm in length, 4mm in width, and 1.5mm in height. The regulator supports an output voltage adjustable from 1.2V up to 37V and delivers up to 1.5A output current, making it suitable for a wide range of electronics and industrial uses.
The device operates with a low quiescent current of 3.5mA, enhancing power efficiency. It includes protection features such as short circuit current limiting, thermal shutdown, and safe-area compensation, which ensure robust and reliable performance even under challenging conditions.
Compliant with AEC-Q100 automotive standards, the LM317LBDR2G is built to endure high temperatures up to 125°C and supports floating operation for high-voltage applications. This makes it an excellent choice for on-card regulation and programmable output scenarios where precise voltage and current control are paramount.
This Voltage Regulator is primarily used in power management systems within electronics components, industrial controls, and automotive electronics, providing stable and adjustable power outputs tailored to specific requirements.
The device operates with low quiescent current for energy efficiency. Compact surface mount SOIC package facilitates easy PCB integration. Maximum input voltage rating supports a wide voltage range up to 37V. Protection circuitry ensures device and system safety under fault conditions.
Industrial and automotive standard compliant for high reliability. Adjustable output voltage from 1.2 to 37 V for flexible voltage regulation. Output current capability up to 1.5 A suits various load demands. Thermal management features maintain stable operation at elevated temperatures.
Explore EnvMart’s extensive range of semiconductor and power management ICs for industrial, automotive, and electronics applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The output voltage of this model is adjustable from 1.25V to 37V.
It can deliver an output current of up to 1.5A.
The maximum input voltage supported by this unit is 37V.
This model has dimensions of 5mm in length, 4mm in width, and 1.5mm in height.
The LM317LBDR2G operates with a quiescent current of 3.5mA.
It can withstand a maximum operating temperature of 125°C.
This voltage regulator is packaged in an 8-pin SOIC surface mount configuration.
It is compliant with the AEC-Q100 automotive standard, ensuring reliability in automotive applications.
It incorporates short circuit current limiting, thermal shutdown, and safe-area compensation for reliable operation.
This model is a positive polarity linear voltage regulator.
It is suitable for on-card regulation and programmable output applications in electronics and industrial control systems.
This voltage regulator is designed for surface mounting.
