binder Circular Connector 5 Contacts Panel Mount Miniature Socket Female IP40 678 Series 99-0616-00-05
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 250V |
| Brand | binder |
| Orientation | Straight |
| Current | 6A |
| IP Rating | IP40 |
| Mount Type | Panel Mount |
| Housing Material | Polyamide |
| Contact Material | Brass |
| Series | 678 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Contact Plating | Silver |
| Number of Contacts | 5 |
| Contact Gender | Female |
| Shell Size | 16 mm |
| Mating Type | Bayonet |
| Connector Size | Miniature |
| Plug/Socket | Socket |
Key Features
- Features 5 contacts with bayonet mating type ensuring secure connection.
- Miniature size with 16 mm shell diameter for compact installations.
- Rated at 250 V and 6 A current for versatile use.
- Constructed with polyamide housing and brass contacts with silver plating for durability.
- Operating temperature range from -40°C to 85°C suitable for harsh environments.
- Panel mount socket female connector with IP40 protection rating.
- Termination by soldering provides reliable electrical connection.
- Straight orientation facilitating easy panel integration.
Product Description
The binder 99-0616-00-05 circular connector is a panel mount miniature socket designed for industrial use, offering high reliability and robust construction. It features 5 contacts configured for secure electrical connections and operates at a voltage of 250 V and current of 6 A, making it suitable for various electronic and power distribution applications.
Its compact 16 mm shell size supports space-saving panel designs, while the bayonet-type mating mechanism ensures a quick and secure connection. The connector housing is made of durable polyamide material, and the contacts are brass with silver plating to enhance conductivity and resistance to corrosion.
Engineered to withstand demanding environments, it operates efficiently within a temperature range of -40°C to 85°C and offers IP40 ingress protection, which protects against solid objects larger than 1 mm. The termination is designed for soldering, facilitating a stable and robust wire connection.
This straight-orientation circular connector is ideal for industrial control systems, instrumentation, and automation setups that require reliable panel-mount interfacing. The product is manufactured in Germany and belongs to the trusted binder 678 series, known for quality and industry compliance despite having no formal standards or approvals listed.
Features 5 contacts with bayonet mating type ensuring secure connection. Miniature size with 16 mm shell diameter for compact installations. Rated at 250 V and 6 A current for versatile use. Constructed with polyamide housing and brass contacts with silver plating for durability.
Operating temperature range from -40°C to 85°C suitable for harsh environments. Panel mount socket female connector with IP40 protection rating. Termination by soldering provides reliable electrical connection. Straight orientation facilitating easy panel integration.
This circular connector is widely used in industrial electronics, manufacturing machinery, control panels, and automation systems. It ensures reliable signal and power transfer, meeting the requirements of demanding industrial environments.
Explore EnvMart for more high-quality circular connectors and related components from reputable brands like binder.
Explore more products in our Industrial Circular Connector category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector is rated at 250 V, making it suitable for various electronic and power distribution applications.
It has a current rating of 6 A, allowing for versatile use in different applications.
The shell diameter of this miniature connector is 16 mm, designed for compact installations.
It features a bayonet mating type, ensuring a secure connection during use.
The housing is made of polyamide, while the contacts are brass with silver plating for enhanced conductivity and corrosion resistance.
It operates efficiently within a temperature range of -40°C to 85°C, suitable for harsh environments.
The connector has an IP40 protection rating, which safeguards against solid objects larger than 1 mm.
The termination is designed for soldering, providing a reliable electrical connection.
This model features a straight orientation, facilitating easy panel integration.
It is manufactured in Germany, ensuring adherence to quality standards.
This circular connector features 5 contacts, configured for secure electrical connections.
It is widely used in industrial electronics, manufacturing machinery, control panels, and automation systems.
