RS PRO Circular Connector 3 Contacts Front Mount Socket Male Threaded IP68 500V 10A Polyamide 66 124-6656

Free Delivery in India | Lowest Global Shipping Charges

RS PRO Circular Connector 3 Contacts Front Mount Socket Male Threaded IP68 500V 10A Polyamide 66 124-6656

Name: RS PRO Circular Connector 3 Contacts Front Mount Socket Male Threaded IP68 500V 10A Polyamide 66 124-6656
Brand: RS PRO
SKU: 142279
Price: 11.46 USD
Availability: InStock



Category Industrial Circular Connector Brand RS PRO Condition New

Specifications

Country of Origin	China
Voltage	500V
Brand	RS PRO
Orientation	Straight
Current	10A
Model	124-6656
IP Rating	IP68
Mount Type	Front
Housing Material	Polyamide 66, Polycarbonate
Contact Material	Brass
Series	RS PRO
Termination Type	Crimp
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Pole Format	3
Contact Plating	Gold
Number of Contacts	3
Contact Gender	Male
Shell Size	17 mm
Mating Type	Threaded
Connector Size	Standard
Plug/Socket	Socket
Cable outer diameter acceptance	6 mm - 10 mm
Panel hole cutout diameter	17 mm

Key Features

This circular connector supports a voltage rating of 500V and a current rating of 10A.
The housing consists of durable Polyamide 66 and Polycarbonate materials ensuring robustness in harsh environments.
Contact pins are brass with gold plating for excellent conductivity and corrosion resistance.
The connector has a standard shell size of 17 mm and accepts cable outer diameters between 6 mm and 10 mm.
Designed for front panel mounting with a hole cutout diameter of 17 mm for easy installation.
Operates reliably from -40°C to 85°C, suitable for demanding industrial use cases.
Termination is crimp type, facilitating secure and easy wiring connections.
The threaded mating type ensures firm and vibration-resistant coupling.

Product Description

RS PRO 124-6656 circular connector is a front mount socket type with 3 brass contacts and male configuration designed for industrial and harsh environment applications. It features an IP68 rating, ensuring protection against dust ingress and water immersion, making it highly reliable in demanding conditions.

The connector is constructed with a high-quality Polyamide 66 and Polycarbonate housing that offers excellent durability and chemical resistance. It supports a voltage rating of 500V and a max current of 10A, suitable for various power and signal transmission applications in industrial and automation systems.

Its crimp termination type and cable diameter acceptance of 6 mm to 10 mm facilitate secure and flexible cable installations. The 17 mm shell size and panel hole cutout diameter enable straightforward integration with standard front mount panels.

Operating temperature ranges from -40°C to 85°C accommodate wide-ranging environmental conditions often found in manufacturing, water treatment, and machinery applications. The gold-plated brass contacts ensure superior conductivity and protect against corrosion.

This product comprises a 3-contact front mount socket with male contacts. It features a threaded mating type and straight orientation for secure connections. IP68 rated for dust-tight and waterproof performance in industrial settings.

Suitable for use in electrical power distribution, automation controls, and harsh environmental conditions. Robust construction materials assure long-term reliability and operational safety.

Ideal for professionals seeking a dependable circular connector for electrical and electronic components, this RS PRO series connector satisfies demands in industrial, manufacturing, and process control environments. Explore the comprehensive RS PRO catalog at EnvMart for compatible connectors and accessories.
