Wurth Elektronik WE-PD 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 470 μH ±20 % 1.4 A Idc 7447709471
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Height | 10mm |
| Length | 12mm |
| Depth | 12mm |
| Packaging | Tape & Reel |
| Series | WE-PD |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 470μH |
| Standards/Approvals | IEC 62024-2-2020, JEDEC JS709B, RoHS, REACH |
| Package/Case | 1210 |
| Maximum DC Current | 1.4A |
| Maximum DC Resistance | 560mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 2MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Recommended solder profile | Reflow |
Key Features
- The inductor supports a maximum DC current of 1.4 A.
- It features a 1210 package size with a length and depth of 12 mm and height of 10 mm.
- Magnetically shielded construction minimizes leakage fields.
- Suitable for automotive use with AEC-Q200 standard compliance.
- Operating temperature ranges from -40°C to 125°C.
- Maximum DC resistance is 560 milliohms, ensuring low losses.
- The recommended solder profile is reflow for surface mount applications.
- Core material is ferrite to provide optimal magnetic properties.
Product Description
Wurth Elektronik model 7447709471 is a 1210 size shielded wirewound surface mount inductor featuring a ferrite core with an inductance of 470 μH and tolerance of ±20 %. The component supports a maximum DC current of 1.4 A, making it suitable for power regulation applications.
Its compact dimensions (12 mm length, 12 mm depth, and 10 mm height) are optimal for surface mount device assemblies. The magnetic shielding design effectively reduces leakage fields, enhancing performance in compact electronic circuits.
Compliant with the automotive AEC-Q200 standard and recognized under IEC 62024-2-2020 and JEDEC JS709B, the inductor is reliable for automotive and industrial applications. The operating temperature range spans from -40°C up to 125°C, ensuring stability under harsh environment conditions.
The inductor exhibits a low maximum DC resistance of 560 milliohms, contributing to minimal power loss and high efficiency. The recommended solder profile is reflow, facilitating automated assembly processes on printed circuit boards.
This wirewound construction inductor is ideal for switching regulators with low operating voltages, integrated DC/DC converters, and graphic cards, especially where extremely high efficiency (greater than 86%) is required.
The inductor supports a maximum DC current of 1.4 A. Package size is 1210 with magnetic shielding to reduce electromagnetic interference. Operating temperature range from -40°C to 125°C allows use in demanding environments.
Low DC resistance ensures minimal power loss during operation. Recommended solder profile is reflow for surface mount assembly. Core material is ferrite, delivering excellent magnetic characteristics. Maximum self-resonant frequency of 2 MHz suits high-frequency electronic circuits.
Complies with automotive and industry standards, ensuring reliability. Packaging is tape and reel, optimized for production line insertion.
This component is essential for industrial electronic manufacturing, automotive electronics, power supply modules, and high-efficiency power regulation systems. Discover more from Wurth Elektronik and explore the Surface Mount Inductors category on EnvMart for comprehensive sourcing options.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance value of 470 μH with a tolerance of ±20 %.
It supports a maximum DC current of 1.4 A, making it suitable for power regulation applications.
The dimensions of this inductor are 12 mm in length, 12 mm in depth, and 10 mm in height.
The recommended solder profile for this surface mount inductor is reflow, which is suitable for automated assembly processes.
It can operate at a maximum temperature of 125°C, allowing use in demanding environments.
The core material is ferrite, which provides optimal magnetic properties for the inductor.
This model complies with AEC-Q200, IEC 62024-2-2020, and JEDEC JS709B standards, ensuring reliability for automotive and industrial applications.
The maximum DC resistance is 560 milliohms, contributing to minimal power loss during operation.
The maximum self-resonant frequency is 2 MHz, making it suitable for high-frequency electronic circuits.
It is packaged in tape and reel format, optimized for production line insertion.
This component is essential for industrial electronic manufacturing, automotive electronics, power supply modules, and high-efficiency power regulation systems.
It features a wirewound construction, which is typical for inductors used in power regulation applications.
