Nexperia Schottky Diode 20 V 1 A Surface-Mount 2-Pin SOD-123F PMEG2010AEH,115
Specifications
| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 1.2mm |
| Length | 1.7mm |
| Model | PMEG2010AEH,115 |
| Width | 2.7mm |
| Mount Type | Surface |
| Series | PMEG2010AEH |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-123F |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 20V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 200μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 9A |
| Maximum Forward Voltage Vf | 430mV |
Key Features
- Maximum continuous forward current of 1 ampere for stable current handling.
- Peak reverse repetitive voltage of 20 volts suitable for low voltage applications.
- Low forward voltage of 430 millivolts ensuring minimal power loss.
- Compact surface-mount SOD-123F package with dimensions 1.7 mm length, 2.7 mm width, and 1.2 mm height.
- Wide operating temperature range from -65°C to +150°C for harsh environments.
- Peak non-repetitive forward surge current rating of 9 amperes for transient protection.
- Extremely low leakage current of 200 microamperes enhancing efficiency.
- Single diode configuration tailored for discrete Schottky rectification tasks.
Product Description
The Nexperia PMEG2010AEH,115 is a high-efficiency Schottky diode designed for surface-mount applications requiring low forward voltage drop and fast switching.
This diode features a maximum continuous forward current of 1 ampere and a peak reverse voltage of 20 volts, making it suitable for power rectification and switching in electronic circuits.
Encased in the SOD-123F surface mount package, the diode measures 1.7 mm in length, 2.7 mm in width, and 1.2 mm in height, ideal for compact electronic designs. Its operating temperature range from -65°C to +150°C suits industrial, commercial, and automotive environments requiring reliability under varied thermal conditions.
The device’s low forward voltage of 430 mV minimizes power dissipation, while its peak non-repetitive surge current rating of 9A ensures protection during transient surges. Featuring negligible power switching losses and low leakage current of 200 μA, this diode supports energy-efficient circuit designs.
Applications include power supply rectification, freewheeling diodes for motors, and general low voltage switching tasks in industrial electronics and consumer devices. Maximum continuous forward current of 1A. Peak reverse repetitive voltage of 20V.
Low forward voltage drop of 430mV. Compact SOD-123F surface mount package. Wide operating temperature range -65°C to 150°C. Peak non-repetitive surge current of 9A. Low leakage current of 200μA. Single diode configuration, Schottky type.
RoHS compliant. New product condition. Choose Nexperia Schottky Diodes for reliable and efficient semiconductor performance. Explore related semiconductor components and Schottky diode solutions at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this diode is 1 ampere.
The peak reverse repetitive voltage rating is 20 volts, suitable for low voltage applications.
The SOD-123F package measures 1.7 mm in length, 2.7 mm in width, and 1.2 mm in height.
This model operates within a temperature range of -65°C to +150°C.
The forward voltage drop is 430 millivolts, which helps minimize power loss.
The peak non-repetitive forward surge current rating is 9 amperes, providing transient protection.
The leakage current is specified at 200 microamperes, enhancing efficiency.
It features a single diode configuration, specifically designed for Schottky rectification tasks.
This diode is suitable for applications such as power supply rectification and freewheeling diodes for motors.
This model has a pin count of 2.
Yes, this diode is RoHS compliant.
The country of origin for this diode is China.
