Winslow 2.54 mm Pitch Right Angle 16 Way Through Hole Turned Pin Open Frame DIL Socket W3450-13TRC
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Winslow |
| Orientation | Right Angle |
| Temperature range | -55°C to +150°C |
| Frame Type | Open Frame |
| Length | 37.49mm |
| Model | W3450-13TRC |
| Depth | 20.35mm |
| Width | 10.92mm |
| Mount Type | Through Hole |
| Housing Material | Polyethylene Terephthalate, Fibreglass Reinforced Polymer |
| Contact Material | Phosphor Bronze |
| Termination Type | Solder |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 16 |
| Pin Type | Turned |
| Row Width | 7.62mm |
Key Features
- The socket has 16 contact points with turned pins for secure connections.
- It features a right angle orientation optimized for circuit board layouts.
- Constructed with phosphor bronze contacts plated with tin for enhanced conductivity.
- Polyethylene terephthalate fiberglass-reinforced housing provides robust insulation.
- Suitable for operating temperatures ranging from -55°C to +150°C.
- Solder termination type ensures sturdiness in PCB mounting.
- The open frame design supports side stacking and PCB integration.
- Manufactured in the United Kingdom, ensuring quality standards.
Product Description
Winslow W3450-13TRC is a high-quality 16 way Through Hole DIL Socket designed for electronic and industrial PCB applications. Featuring a 2.54 mm pitch and right angle orientation, this turned pin open frame socket ensures secure and reliable connections in densely packed electronic circuits.
The socket’s contacts are made from phosphor bronze with tin plating, offering excellent electrical conductivity and corrosion resistance. Its housing is constructed from polyethylene terephthalate reinforced with fiberglass, providing outstanding mechanical strength and thermal stability.
With a temperature range from -55°C to 150°C, this DIL socket is suitable for demanding environments. The solder termination type guarantees a solid attachment to printed circuit boards, supporting industrial, laboratory, and manufacturing uses.
The open frame design facilitates signal transmission between PCB terminations and socket contacts via an epoxy glass resin printed circuit board. This product is ideal for use with opto-electronic displays and other electronic components requiring up to 16 connections on a 0.1 inch by 0.3 inch pitch grid.
The socket has 16 contact points with turned pins for secure connections. Right angle orientation optimizes PCB layout space. Phosphor bronze contacts with tin plating for electrical reliability. Fiberglass reinforced polyethylene terephthalate housing ensures durability.
Operating temperature range of -55°C to +150°C suits demanding environments. Solder termination provides strong, lasting PCB mounting. Open frame design supports easy side stacking and integration. Compact dimensions (37.49 mm length, 10.92 mm width, 20.35 mm depth).
Manufactured in the United Kingdom with high quality standards.
This Winslow DIL Socket is suitable for use in industrial electronics, laboratory instrumentation, and manufacturing equipment requiring reliable electrical connections. It is an essential component for engineers and technicians designing and repairing PCBs that demand precision and durability.
Explore more in EnvMart’s Electronics Components category for a wide range of sockets and connectors to meet diverse application needs.
