RS PRO 2.54 mm Pitch Vertical 14 Way Through Hole Turned Pin Closed Frame DIL Socket 3A 183-1565

RS PRO 183-1565 is a high-quality DIL Socket designed for reliable and repeatable connections in electronics manufacturing. This 14-way vertical socket features a 2.54 mm pitch and turned pin contacts with a closed frame design. Its through-hole mounting type provides secure soldered connection on PCB assemblies.

The socket is constructed from robust thermoplastic housing paired with beryllium copper alloy and brass contacts plated with tin to ensure durability and good electrical conductivity. It supports currents up to 3A and voltages up to 60V AC, making it suitable for various low-power electronic circuit designs.

Operating temperature range from -40°C to 105°C enables use in demanding industrial, laboratory, and electronic assembly environments. The closed frame eliminates flux intrusion and solder wicking, ensuring long service life and reliable performance during repeated insertion and withdrawal cycles.

The compact size of 17.78 mm length, 10.16 mm width, and 3 mm depth allows designers to conserve space in densely populated PCBs. Its vertical orientation and solder termination type provide ease of assembly for mass production or prototype builds.

This socket finds applications in electronics manufacturing, repair, testing setups, and other industrial or commercial electronic projects that require dependable DIP socket solutions.

Supports current rating up to 3A for industrial electronic applications. Features 14 precision turned pins arranged in a 2.54 mm pitch vertical configuration. Constructed with a closed frame to prevent solder flux intrusion and solder wicking.

Manufactured using thermoplastic housing with beryllium copper alloy and brass contacts plated in tin. Rated for operating temperatures from -40°C to 105°C ensuring durable performance. Designed for through-hole solder mounting on printed circuit boards.

Compact dimensions of 17.78 mm length, 10.16 mm width, and 3 mm depth enable space-efficient designs. Voltage rating of 60V AC suitable for low-voltage circuit applications. Vertical orientation facilitates easy insertion and withdrawal with repeated use.

Made in China and suitable for electronic manufacturing, repair, and prototyping environments. Explore more electronic connectors and DIL Sockets to find compatible components for your projects and manufacturing needs at EnvMart.
