Preci-Dip 2.54 mm Pitch Vertical 22 Way Through Hole Turned Pin Open Frame DIL Socket 110-87-322-41-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 100, 150V ac |
| Brand | Preci-Dip |
| Orientation | Vertical |
| Current | 1A |
| Frame Type | Open Frame |
| Length | 27.8mm |
| Depth | 2.8mm |
| Width | 10.1mm |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass, Beryllium Copper Alloy |
| Series | 110 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.54mm |
| Contact Plating | Gold, Tin |
| Number of Contacts | 22 |
| Pin Type | Turned |
| Row Width | 7.62mm |
| Stock numbers | 702-0691 , 702-2704 , 702-2701 , 702-2713 , 702-2767, 702-2779 , 702-2773 , 702-2798 and 702-2808 are without a centre bar |
Key Features
- Offers reliable current rating of 1A suitable for low power applications.
- Features gold and tin plated contacts for enhanced conductivity and corrosion resistance.
- Made with brass and beryllium copper alloy contact materials ensuring durability.
- Constructed with fibreglass reinforced polyethylene terephthalate housing for mechanical strength.
- Open frame design allows easy inspection and ensures optimal ventilation.
- Operates at voltages of 100 to 150V AC with vertical orientation on PCB.
- Temperature range from -55°C minimum to 125°C maximum for versatile operating environments.
- Termination type is solder suitable for through-hole printed circuit board assembly.
Product Description
Preci-Dip 110-87-322-41-001101 is a high-quality, Swiss-manufactured Dual-In-Line (DIL) socket featuring a 2.54 mm pitch and 22 electrical contacts.
Designed specifically for vertical orientation and through-hole mounting, this open frame socket uses turned pin contacts that provide a secure and precise electrical connection to printed circuit boards.
The socket's contact plating combines gold and tin layers, enhancing conductivity and ensuring long-lasting corrosion resistance, while the contact materials consist of brass and beryllium copper alloy for superior electrical and mechanical performance.
The housing is made of fibreglass reinforced polyethylene terephthalate, giving it robust mechanical strength suitable for industrial and laboratory electronic assemblies. This socket supports a current rating of 1 amp and voltage range of 100 to 150 volts AC, operating reliably across a broad temperature range from -55°C to 125°C.
Its open frame structure facilitates better ventilation and visual inspection during assembly and maintenance. Reliable 1A current rating for low-power circuits. Gold and tin contact plating for durability and conductivity.
Brass and beryllium copper alloy contact materials provide mechanical and electrical strength. Fibreglass reinforced housing ensures robust mechanical resilience. Through-hole mount and solder termination for secure PCB integration.
Compact dimensions optimizing space on circuit boards. Manufactured in Switzerland ensuring premium quality standards. Wide operating temperature range suitable for diverse applications. Vertical orientation ideal for specific PCB designs.
Open frame design facilitating inspection and ventilation.
This Preci-Dip 110 series socket is ideal for industrial, electronics manufacturing, testing equipment, and laboratory applications requiring reliable, precision DIL socket connectors.
Explore more high-quality electronic components and connectors in the DIL Socket category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a reliable current rating of 1 amp, making it suitable for low-power applications.
It operates at voltages ranging from 100 to 150 volts AC.
The contacts are made from brass and beryllium copper alloy, ensuring strong electrical and mechanical performance.
It can operate reliably within a temperature range of -55°C to 125°C.
This socket features a solder termination type, suitable for through-hole printed circuit board assembly.
The pitch size is 2.54 mm, which is standard for many electronic applications.
It has 22 electrical contacts, providing multiple connection points for circuit integration.
The housing is made of fibreglass reinforced polyethylene terephthalate, which offers robust mechanical strength.
This model features an open frame design, which allows for easy inspection and optimal ventilation.
It measures 27.8 mm in length, 10.1 mm in width, and 2.8 mm in depth.
It is manufactured in Switzerland, ensuring adherence to premium quality standards.
