Preci-Dip 8 Way SIL Socket Straight Through Hole 2.54 mm Pitch 100 V AC 150 V DC 3A 801-87-008-10-012101

Preci-Dip 801-87-008-10-012101 8 Way SIL Socket is a high-quality electronic component designed for industrial, manufacturing, and laboratory applications requiring reliable signal and power connections on PCBs.

This socket features 8 contacts with a 2.54 mm pitch, allowing precise and secure placement of integrated circuits. The contacts are composed of beryllium copper alloy and brass, plated with gold and tin to enhance conductivity and prevent corrosion, ensuring long-term performance even in harsh operating environments.

The socket employs a straight through hole mount type suitable for solder termination on printed circuit boards. It has an operating voltage of 100 V AC and 150 V DC with a maximum current rating of 3 A. The housing is constructed from fibreglass reinforced polycyclohexylenedimethylene terephthalate, which offers excellent mechanical strength and thermal resilience, operating reliably within a temperature range of -55°C to 125°C.

Dimensionally, the socket measures 20.32 mm in length and 2.54 mm in width, with a depth of 4.2 mm, making it compatible with various PCB designs and assembly processes. This component is manufactured in Switzerland, reflecting superior craftsmanship and adherence to rigorous quality standards.

Ideal for applications in electronic assembly lines, quality test equipment, instrumentation, and telecommunications hardware, this Preci-Dip SIL Socket assists in improving production efficiency and connection reliability. It supports through hole soldering processes, making it compatible with standard PCB manufacturing workflows.

This SIL socket supports a current rating of 3A for reliable performance. Contacts are made from beryllium copper alloy and brass for durability. Gold and tin plating ensures excellent conductivity and corrosion resistance.

Designed for through hole solder mounting at 100 V AC and 150 V DC ratings. Housing consists of fibreglass reinforced polycyclohexylenedimethylene terephthalate for high temperature resistance. Operational temperature ranges from -55°C to 125°C for versatile applications.

Compact dimensions include 20.32 mm length and 2.54 mm width suitable for PCB designs. Manufactured in Switzerland ensuring premium quality and precision engineering. Explore more components and connectors at EnvMart to support your industrial electronics projects with trusted quality and detailed specifications.
