HARWIN 20 Way Vertical Through Hole 2.54 mm Pitch SIL Socket Solder Termination 1A D01-9972042

HARWIN D01-9972042 is a 20 Way Vertical Through Hole SIL Socket designed for electronic components requiring precise and reliable connections on printed circuit boards. This socket features 20 contacts configured in a single row aligned vertically with a 2.54 mm pitch, ensuring standard spacing suitable for various IC and electronic applications.

The contact parts are crafted from beryllium copper alloy, chosen for its superior electrical conductivity and mechanical strength. Each contact is plated with gold over nickel, providing excellent resistance against oxidation and wear, thus enhancing the reliability of electrical contacts over prolonged use.

The housing is constructed from polycyclohexylenedimethylene terephthalate, which provides robust mechanical and thermal stability. This allows operation in harsh environments with a temperature range from -55°C to +125°C, suitable for industrial, laboratory, and manufacturing settings where durable and heat-resistant sockets are required.

The through hole mounting style with solder termination allows for secure installation on PCBs, making it ideal for applications such as electronics assembly, prototype development, and maintenance of electrical devices. The socket supports pins with diameter ranging from 0.40mm to 0.56mm, accommodating a wide range of component leads.

Equipped with 20 contacts providing reliable interface points. Contacts made from beryllium copper alloy ensuring excellent conductivity. Gold plating over nickel for corrosion resistance and long service life. Vertical orientation facilitates straightforward through-hole PCB mounting.

Housing material is polycyclohexylenedimethylene terephthalate for thermal and mechanical resilience. Temperature rating from -55°C to 125°C for harsh environment use. Solder termination for robust electrical and mechanical connection.

Pin diameter compatibility from 0.40mm to 0.56mm increases versatility.

This HARWIN SIL socket is widely used in electronics manufacturing, testing equipment, communication devices, and industrial control systems. Its robust construction and precise specifications make it a trusted component for professional engineers and technicians.
