Preci-Dip 9 Way Preci-Dip Straight Surface 2.54 mm Pitch SIL Socket 150V dc, Solder, 3A 801-87-009-30-002191
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V dc |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3A |
| Length | 22.86mm |
| Depth | 2.95mm |
| Width | 2.54mm |
| Mount Type | Surface |
| Housing Material | Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate |
| Contact Material | Beryllium Copper Alloy, Brass |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.54mm |
| Contact Plating | Tin, Gold |
| Number of Contacts | 9 |
Key Features
- Features nine contacts for versatile connectivity.
- Constructed with beryllium copper alloy and brass for durability.
- Contact plating includes tin and gold for corrosion resistance.
- Designed for straight surface mounting with solder termination.
- Durable fibreglass reinforced polycyclohexylenedimethylene terephthalate housing.
- Operates within temperature range of -55°C to 125°C.
- Suitable for use in electronic, industrial, and manufacturing applications.
- Manufactured in Switzerland ensuring high quality standards.
Product Description
Preci-Dip 801-87-009-30-002191 9 Way SIL Socket is a precision-engineered connector designed for electronic component interconnections. This socket features a 2.54 mm pitch between contacts and supports a maximum voltage of 150V dc and current of 3A, making it suitable for demanding electrical applications.
The socket’s contacts are made from a beryllium copper alloy combined with brass, offering excellent electrical conductivity and mechanical strength. Its contact plating of tin and gold provides optimal corrosion resistance and reliable signal integrity. The housing is constructed from fibreglass reinforced polycyclohexylenedimethylene terephthalate, ensuring durability and resistance to high temperatures, with an operating range from -55°C to 125°C.
Designed for straight surface mounting with solder termination, this SIL socket provides ease of installation and strong mechanical retention. Its compact dimensions of 22.86 mm length, 2.54 mm width, and 2.95 mm depth allow usage in space-constrained electronic assemblies.
Features nine contacts for versatile connectivity. Constructed with beryllium copper alloy and brass for durability. Contact plating includes tin and gold for corrosion resistance. Designed for straight surface mounting with solder termination.
Durable fibreglass reinforced housing ensures thermal and mechanical stability. Wide operating temperature range accommodates various environmental conditions. Compact size fits into dense electronic circuit boards. Manufactured to Swiss quality standards for reliable performance.
Ideal for electronic manufacturing, industrial controls, and power connectors.
This Preci-Dip SIL Socket is suitable for industrial electronics, manufacturing, telecommunications, and laboratory equipment. It supports efficient assembly and offers superior electrical connections for critical applications.
Explore the Electronics Components category for similar high-quality connectors and sockets at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating of this SIL socket is 150V dc.
It supports a maximum current capacity of 3A.
The socket has a length of 22.86 mm, a width of 2.54 mm, and a depth of 2.95 mm.
The contacts are made from a beryllium copper alloy combined with brass.
This model utilizes solder termination for connection.
It operates within a temperature range of -55°C to 125°C.
The pitch between the contacts is 2.54 mm.
The housing is constructed from fibreglass reinforced polycyclohexylenedimethylene terephthalate.
This model features nine contacts for versatile connectivity.
The socket is designed for straight surface mounting.
It is suitable for electronic manufacturing, industrial controls, telecommunications, and laboratory equipment.
It is manufactured in Switzerland, ensuring high quality standards.
