TDK Film Capacitor 220 nF 40V AC 63 V DC Through Hole 2 Pin Pitch 5mm B32529C0224J000

Free Delivery in India | Lowest Global Shipping Charges

TDK Film Capacitor 220 nF 40V AC 63 V DC Through Hole 2 Pin Pitch 5mm B32529C0224J000



Category Film Capacitor Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Height	6.5mm
Length	7.2mm
Model	B32529C0224J000
Width	2.5mm
Mount Type	Through Hole
Series	B32529
Maximum Operating Temperature	125°C
Capacitance	220nF
Standards/Approvals	RoHS, UL
Pin Count	2
Rated AC Voltage	40V ac
Rated DC Voltage	63V dc
Lead Pitch	5mm
Lead Diameter	0.5mm
Automotive Standard	AEC-Q200 Rev D

Key Features

Rated for 40V AC and 63V DC operation.
Employs stacked-film technology for enhanced performance and reliability.
Plastic case sealed with epoxy resin provides UL 94 V-0 flame retardancy.
Pin pitch measures 5 mm with lead diameter of 0.5 mm.
Complies with automotive standard AEC-Q200 Rev D for high pulse strength.
Maximum operating temperature of 125°C ensures suitability for harsh environments.
Compact size with dimensions 7.2 mm length, 6.5 mm height, and 2.5 mm width.
2-pin through-hole mount style for easy PCB assembly.

Product Description

TDK B32529C0224J000 is a high-quality film capacitor designed for applications requiring robust capacitance and high reliability. Featuring 220 nF capacitance with a rated AC voltage of 40V and a DC voltage rating of 63V, it is ideally suited for blocking, coupling, decoupling, and bypassing tasks as well as radio frequency interference (RFI) suppression in automotive and industrial electronics.

This capacitor series employs stacked-film technology, delivering high pulse strength and excellent contact reliability. Its plastic case is sealed with epoxy resin rated UL 94 V-0, providing flame retardant properties to enhance safety in demanding environments.

The B32529C0224J000 model features a 2-pin through-hole mount with a lead pitch of 5 mm and lead diameter of 0.5 mm, facilitating secure PCB assembly. It complies with AEC-Q200 Rev D automotive standards, ensuring suitability for automotive electronic systems with stringent quality requirements. The component supports a maximum operating temperature of 125°C, making it suitable for use in high-temperature conditions.

Compact dimensions of 7.2 mm length, 6.5 mm height, and 2.5 mm width make this capacitor space efficient for dense circuit boards. It is RoHS and UL approved, confirming compliance with environmental and safety standards.

Rated 40 V AC and 63 V DC voltage handling capacity. AEC-Q200 Rev D automotive standard compliance. Flame-retardant plastic case with epoxy resin sealing. Stacked-film technology offering high pulse strength. Compact through-hole component with 2-pin 5 mm lead pitch.

Maximum operating temperature up to 125°C for harsh environments. RoHS and UL certified ensuring compliance standards.

This Film Capacitor is ideal for use in industrial electronics, automotive systems, power supplies, consumer electronics, and general electronic components assembly. Its reliable performance and compliance with automotive standards make it particularly valuable in automotive electronics manufacturing and repair sectors.

For high reliability and compact design capacitors, explore the extensive range available at EnvMart, ensuring selection of genuine parts from trusted brands like TDK.
