Vishay 10.2 V 500 mW General Purpose Zener Diode, Single Surface 2-Pin DO-219AC (MicroSMF) PLZ10C-HG3_A/H

Free Delivery in India | Lowest Global Shipping Charges

Vishay 10.2 V 500 mW General Purpose Zener Diode, Single Surface 2-Pin DO-219AC (MicroSMF) PLZ10C-HG3_A/H

Name: Vishay 10.2 V 500 mW General Purpose Zener Diode, Single Surface 2-Pin DO-219AC (MicroSMF) PLZ10C-HG3_A/H
Brand: Vishay
SKU: 110921
Price: 0.07 USD
Availability: InStock



Category Zener Diodes Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	0.6mm
Length	2.5mm
Model	PLZ10C-HG3_A/H
Mount Type	Surface
Series	PLZ
Maximum Operating Temperature	150°C
Package Type	DO-219AC (MicroSMF)
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	20mA
Maximum Reverse Leakage Current	200nA
Nominal Zener Voltage Vz	10.2V
Zener Type	General Purpose
Maximum Zener Impedance	8Ω

Key Features

Nominal Zener voltage of 10.2 volts ensuring precise voltage regulation.
Maximum power dissipation capped at 500 mW providing stable operation.
Low leakage current of 200 nA enhances efficiency in voltage-sensitive circuits.
Compact DO-219AC (MicroSMF) surface mount package measuring 2.5 mm length and 0.6 mm height.
Compliance with IEC 61760-1, IEC 61000-4-2, and RoHS standards for quality assurance.
Automotive standard certified with AEC-Q101, suitable for demanding applications.
Wide operating temperature range from -55°C to 150°C for reliable performance.
Test current at 20 mA and maximum Zener impedance of 8 ohms for consistent operation.

Product Description

Vishay PLZ10C-HG3_A/H is a high-quality 10.2 V Zener diode designed for surface mount applications, featuring a general purpose Zener type and single diode configuration. It supports 500 mW maximum power dissipation and operates reliably in a wide temperature range from -55°C to 150°C, making it suitable for various industrial, automotive, and electronic equipment.

This diode uses silicon planar technology in an ultra-small MicroSMF (DO-219AC) package, with a length of 2.5 mm and height of 0.6 mm, providing excellent stability and low leakage current of 200 nA which ensures efficiency in voltage regulation circuits. The diode has a test current of 20 mA and a maximum Zener impedance of 8 ohms that contributes to consistent performance under load.

Compliant with IEC 61760-1, IEC 61000-4-2 standards and RoHS directive, the PLZ series diodes are also qualified to the automotive AEC-Q101 standard assuring suitability for automotive electronics and harsh environments. Their wave and reflow solderability with a high temperature soldering tolerance of 260°C at the terminals allows for easy PCB assembly.

These characteristics make the Vishay PLZ10C-HG3_A/H Zener diode ideal for use in power supply regulation, voltage reference circuits, and protection against voltage spikes in industrial, automotive, laboratory, and consumer electronic applications.

Nominal Zener voltage of 10.2 volts ensuring precise voltage regulation. Maximum power dissipation capped at 500 mW providing stable operation. Low leakage current of 200 nA enhances efficiency in voltage-sensitive circuits.

Compact DO-219AC (MicroSMF) surface mount package measuring 2.5 mm length and 0.6 mm height. Compliance with IEC 61760-1, IEC 61000-4-2, and RoHS standards for quality assurance. Automotive standard certified with AEC-Q101, suitable for demanding applications.

Wide operating temperature range from -55°C to 150°C for reliable performance. Test current at 20 mA and maximum Zener impedance of 8 ohms for consistent operation. Explore more Zener Diodes and related components to suit your electronic and industrial needs with EnvMart's extensive electronics category.
