Wurth Elektronik Wirewound Surface Mount Inductor 2.2μH Semi Shielded ±20% 1.8A Idc 252012 WE-LQS 74404024022
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 1.2mm |
| Length | 2.5mm |
| Depth | 2mm |
| Packaging | Tape & Reel |
| Series | WE-LQS |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Inductance | 2.2μH |
| Standards/Approvals | RoHS |
| Package/Case | 252012 |
| Maximum DC Current | 1.8A |
| Maximum DC Resistance | 80mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 55MHz |
| Inductor Construction | Semi Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact 252012 package with 2.5mm length and 1.2mm height dimensions.
- Automotive standard AEC-Q200 compliant for reliable operation.
- Maximum DC resistance of 80mΩ ensuring low power loss.
- Maximum operating temperature up to 125°C suitable for harsh conditions.
- Magnetically shielded semi shielded inductor construction reduces EMI.
- Surface mount termination style for efficient PCB assembly.
- Maximum self-resonant frequency of 55MHz for high frequency performance.
- Packaging by tape and reel format optimized for manufacturing processes.
Product Description
Wurth Elektronik 74404024022 WE-LQS series wirewound surface mount inductor offers 2.2μH inductance with a semi shielded construction, designed to provide excellent magnetic shielding and enhanced current management capabilities up to 1.8A (Idc). This compact 252012 package inductor measures 2.5mm in length, 2mm in depth, and 1.2mm in height, making it suitable for high-density applications.
Compliant with automotive standard AEC-Q200, these inductors ensure high reliability in demanding automotive and industrial environments. Their low DC resistance of 80mΩ minimizes power loss, while the maximum operating temperature of 125°C supports operations in elevated temperature conditions.
The magnetic shielding reduces electromagnetic interference, enhancing performance in sensitive electronic circuits. Surface mount termination style allows for efficient automated PCB assembly and manufacturing.
Typical applications include switching controllers, DC/DC converters, portable power devices, and other electronic equipment requiring compact, robust inductors with high current capacity and stable inductance.
Inductors of this type are ideal for electronics manufacturing, industrial electronics, automotive power supplies, and consumer electronic devices where space savings and performance are critical.
Compact 252012 package with 2.5mm length and 1.2mm height dimensions. Automotive standard AEC-Q200 compliant for reliable operation. Maximum DC resistance of 80mΩ ensuring low power loss. Maximum operating temperature up to 125°C suitable for harsh conditions.
Magnetically shielded semi shielded inductor construction reduces EMI. Surface mount termination style for efficient PCB assembly. Maximum self-resonant frequency of 55MHz for high frequency performance. Packaging by tape and reel format optimized for manufacturing processes.
Explore more Surface Mount Inductors from Wurth Elektronik and related electronics components available on EnvMart for your industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 2.2μH.
The dimensions of the 252012 package are 2.5mm in length, 2mm in depth, and 1.2mm in height.
The maximum DC current rating for this inductor is 1.8A.
The maximum operating temperature is 125°C, making it suitable for harsh conditions.
Yes, this inductor is compliant with the automotive standard AEC-Q200, ensuring reliable operation in automotive applications.
The maximum DC resistance is 80mΩ, which helps minimize power loss.
The maximum self-resonant frequency of this model is 55MHz, suitable for high-frequency applications.
This inductor features a surface mount termination style, allowing for efficient PCB assembly.
The inductor is packaged in tape and reel format, optimized for manufacturing processes.
The minimum operating temperature is -40°C and the maximum is 125°C.
This inductor is suitable for applications such as switching controllers, DC/DC converters, and portable power devices.
The inductor has a semi-shielded construction, which reduces electromagnetic interference (EMI).
