Weidmüller LSF Series PCB Terminal Block 4-Contact 7.5 mm Pitch 1 Row 800V Push-in Connection 1473860000
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 800V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | 180° |
| Current | 17.5A |
| Depth | 10.5mm |
| Width | 26.7mm |
| Housing Material | Fibreglass Liquid Crystal Polymer |
| Series | LSF |
| Number of Rows | 1 |
| Pitch | 7.5mm |
| Standards/Approvals | CSA, RoHS, UL |
| Number of Contacts | 4 |
| Minimum Wire Size mm² | 0.13mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Push-in |
Key Features
- Constructed with fibreglass liquid crystal polymer housing for durability.
- Supports current up to 17.5 A for robust electrical performance.
- Compatible with wire sizes from 0.13 mm² to 1.5 mm² (28 AWG to 14 AWG).
- Offers 180° orientation with easy push-in conductor connection system.
- Meets CSA, RoHS, and UL standards ensuring safety and compliance.
- Designed for automatic assembly using reflow soldering processes.
- Color coded with black housing for straightforward identification.
Product Description
Weidmüller 1473860000 PCB Terminal Block is a reliable and compact 4-contact connector designed for printed circuit boards (PCB). It features a 7.5 mm pitch with a single-row layout and supports conductor connections via a convenient push-in system. Rated for 800 V and 17.5 A current capacity, this terminal block is engineered with fibreglass liquid crystal polymer housing which provides excellent mechanical strength and thermal resistance.
This component supports a wide range of wire sizes from 0.13 mm² to 1.5 mm² (28 AWG to 14 AWG), enabling versatile application in electronic assemblies. The 180° conductor orientation facilitates ergonomic wiring and secure contact insertion. The terminal block is suitable for fully automatic SMT assembly processes, including reflow soldering, making it ideal for industrial-scale manufacturing.
Its compact dimensions of 26.7 mm width and 10.5 mm depth allow efficient PCB space utilization, while the black color housing assists in product differentiation. The product complies with key industry standards such as CSA, RoHS, and UL, confirming its suitability for safety-conscious environments.
The Weidmüller Omnimate and LSF series terminal blocks utilize advanced connection technology offering an easy push-in mechanism for solid wires or ferrules without the need for tools. This enables faster assembly and maintenance operations in electronic, industrial, and commercial applications.
Constructed with fibreglass liquid crystal polymer housing for enhanced durability and thermal stability. Handles electrical currents up to 17.5 A ensuring high performance in demanding circuits. Wire size compatibility from 0.13 mm² to 1.5 mm² (28 AWG to 14 AWG) provides versatility.
Push-in wire connection technology facilitates tool-free conductor insertion. Compact design with 7.5 mm pitch and single row layout for efficient PCB mounting. Complies with international standards CSA, RoHS, and UL for safety assurance.
Optimized for automatic assembly including reflow and vapor phase soldering.
This terminal block is ideal for electronic manufacturing, power distribution, and control panel applications where reliable and secure PCB connections are essential. Explore our range of Weidmüller products for additional options in terminal blocks and connection technology at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block supports a current rating of up to 17.5 A, ensuring robust electrical performance in various applications.
It is rated for a voltage of 800 V, making it suitable for high-voltage applications.
This terminal block is compatible with wire sizes ranging from 0.13 mm² to 1.5 mm² (28 AWG to 14 AWG).
The terminal block features a 7.5 mm pitch and has a 180° orientation for easy conductor connection.
It utilizes a push-in connection method, allowing for tool-free conductor insertion.
The dimensions are 26.7 mm in width and 10.5 mm in depth, allowing for efficient PCB space utilization.
It meets CSA, RoHS, and UL standards, ensuring safety and compliance for various applications.
It is constructed with fibreglass liquid crystal polymer housing, providing durability and thermal stability.
Yes, it is optimized for automatic assembly, including reflow and vapor phase soldering processes.
This model features 4 contacts, making it suitable for various connection needs.
It is ideal for electronic manufacturing, power distribution, and control panel applications where reliable PCB connections are essential.
The housing is black, which assists in product differentiation and identification.
