onsemi Logic Level Translator 3 LVTTL/LVCMOS to LVPECL 8-Pin SOIC MC100LVELT22DG

onsemi MC100LVELT22DG is a high-performance logic level translator designed for uni-directional conversion of 3 LVTTL/LVCMOS input signals to LVPECL outputs. This 8-pin SOIC surface-mount device is engineered to facilitate interfacing between different logic voltage families, supporting applications that require seamless integration of LVTTL/LVCMOS and LVPECL signaling.

The device features a maximum propagation delay time of 660 picoseconds at the specified load capacitance, ensuring rapid signal transitions suitable for high-speed digital applications. It operates over a supply voltage range of 3V to 3.8V and maintains reliable function across a wide temperature range from -40°C to 85°C, making it well-suited for diverse industrial and commercial electronic environments.

With three translator elements integrated on a single chip, the MC100LVELT22DG delivers efficient channel density for compact system designs. Its surface-mount SOIC package measures 5mm in length and 1.5mm in height, enabling space optimization on PCBs.

The translator IC supports maximum low-level and high-level output currents of 50mA and 100mA respectively, providing robust drive capability for downstream components. It is designed to interface with differential logic families including ECL, PECL, CML, LVDS, HSTL, HCSL, TTL, and CMOS, offering versatile application in communication, signal processing, and industrial control systems.

Uni-directional logic level translation from LVTTL/LVCMOS to LVPECL. Compact 8-pin SOIC surface mount package. Three translator elements per chip improve signal routing density. Wide operating temperature range from -40°C to 85°C for harsh environments.

Maximum propagation delay of 660 picoseconds supports high-frequency switching. Supply voltage from 3V to 3.8V ensures compatibility with varying power rails. Maximum output currents: 50mA low level, 100mA high level. Compact dimensions (5mm length x 1.5mm height) facilitate PCB space saving.

Compatible with multiple differential logic standard families including ECL and PECL.

This logic level translator IC is ideal for use in industrial automation, telecommunications, networking equipment, and other electronic systems requiring precise and reliable signal level shifting between incompatible logic standards. The compact SOIC package enables its use in dense PCB layouts, and the extended temperature range ensures reliability under industrial conditions.
