Samtec MPT Series Right Angle Through Hole PCB Header, 2 Contacts, 5 mm Pitch, 1 Row, Shrouded MPT-02-01-01-L-RA-SD
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 848V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 39A |
| Temperature range | -55 → 125 °C |
| Model | MPT-02-01-01-L-RA-SD |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | MPT |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 5mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
| Insulator Material | Black LCP |
| MPT-xx-6.30-01-L-V | Height 6.3 mm, Vertical |
| MPT-xx-01-01-L-RA-SD | Right Angle with Screw Down holes |
Key Features
- Constructed with liquid crystal polymer housing for high durability.
- Male contacts plated with 0.25 μm gold for excellent conductivity and corrosion resistance.
- Operates reliably between -55°C to 125°C temperature range.
- Feature shrouded design ensuring secure mating and alignment.
- Mount type through hole with screw down holes for robust mechanical stability.
- Designed for use on 1.6 mm thick PCBs with 5 mm row pitch.
- Current rating of 39A and voltage rating up to 848 V.
- Termination type is solder for secure electrical connections.
Product Description
Samtec MPT-02-01-01-L-RA-SD is a Right Angle Through Hole PCB Header designed for high current applications with a current rating of 39A and voltage rating of 848 V. It features 2 male contacts with 5 mm pitch arranged in a single row and housed in a durable black Liquid Crystal Polymer (LCP) insulator.
The connector incorporates 0.25 μm gold plating on contacts for superior electrical performance and matte tin plating on PCB tails. Its shrouded design adds protection and ensures proper alignment during installation. The board-to-board mount system is via through hole termination with screw down holes of 3.56 mm diameter for enhanced mechanical strength.
This PCB header supports a wide operating temperature range from -55°C to 125°C, making it suitable for demanding industrial, electronic, and manufacturing applications. It accommodates 1.6 mm thick PCBs and maintains a 5 mm pitch row spacing.
Applications of the MPT Series include power electronics, telecommunications equipment, industrial machines, and other devices requiring reliable electrical connections under harsh conditions.
Constructed with black liquid crystal polymer housing for robustness. Gold-plated copper alloy contacts ensure durability and conductivity. Designed for right angle orientation with secure screw down mounting. Operates in a temperature range from -55°C to 125°C.
Suitable for board thickness 1.6 mm and 5 mm row pitch. Supports high current up to 39A and voltage rating of 848 V. Shrouded design prevents accidental pin damage and improves mating reliability. Ideal for industrial, laboratory, and commercial electronic assembly use cases.
Explore more PCB Headers and connectors on EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 39A, making it suitable for high current applications.
The voltage rating for this PCB header is up to 848V, allowing it to be used in various electrical applications.
It operates reliably within a temperature range of -55°C to 125°C, suitable for demanding environments.
This unit features a through hole mounting type with screw down holes for enhanced mechanical stability.
The housing is made from liquid crystal polymer, while the contacts are copper alloy with gold plating for conductivity.
It has 2 male contacts arranged in a single row, designed for efficient electrical connections.
The pitch size for this model is 5 mm, which is standard for many PCB applications.
The shrouded design helps prevent accidental pin damage and ensures proper alignment during mating.
The termination type is solder, providing secure electrical connections on the PCB.
It is designed for use on PCBs that are 1.6 mm thick, ensuring compatibility with standard board sizes.
This series is suitable for applications in power electronics, telecommunications equipment, and industrial machines.
The country of origin for this model is India.
