Samtec IPL1 Series Right Angle Through Hole PCB Header, 24 Contacts, 2.54 mm Pitch, 2 Row, Shrouded IPL1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 675V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 3.8A |
| Model | IPL1 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | IPL1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 24 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- The header features 24 contacts arranged in 2 rows with a 2.54 mm pitch.
- Constructed with a liquid crystal polymer housing for durability.
- Phosphor bronze contacts plated with gold ensure reliable electrical performance.
- Rated for a current of 3.8 A and voltage up to 675 V.
- Right angle orientation with shrouded design enhances protection and connection stability.
- Suitable for through-hole mounting with solder termination.
- Operates reliably in temperatures ranging from -55°C to 125°C.
- Ideal for electronics applications requiring robust PCB connectors.
Product Description
Samtec IPL1 Series Right Angle Through Hole PCB Header IPL1 is a high-quality connector designed for wire-to-board applications with through-hole mount type. Featuring 24 male contacts arranged in 2 rows with a standard 2.54 mm pitch, this shrouded header ensures secure and reliable connections in electronic devices.
The housing is made of liquid crystal polymer, providing excellent durability and resistance under industrial conditions. Contacts made from phosphor bronze with gold plating guarantee consistent conductivity and corrosion resistance. Rated for 3.8 A current and 675 V voltage, it supports demanding electrical requirements.
This right angle connector is terminated via soldering, suitable for assembly in electronics manufacturing environments. It operates effectively across a wide temperature range (-55°C to 125°C), making it versatile for various industrial, laboratory, electronic manufacturing, and commercial uses.
The header offers 24 contacts in 2 rows with 2.54 mm pitch. Housing material is liquid crystal polymer for mechanical strength. Phosphor bronze gold-plated contacts provide reliable electrical performance. Supports 3.8 A current and up to 675 V voltage.
Shrouded and right angle for protection and secure placement. Through-hole mount type with solder termination enhances mechanical stability. Wide operating temperature range from -55°C to 125°C for diverse environments.
This PCB Header is suitable for electronic assembly in industrial equipment, communication devices, instrumentation, and other technical applications requiring robust connectors. Its environmental and electrical endurance supports long-term reliability.
Explore more Samtec connectors and electronic components at EnvMart for your project and manufacturing needs.
