| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 2.7mm |
| Model | BZT52C5V6S-7-F |
| Mount Type | Surface |
| Series | BZT52C5V6S |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 200mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 3μA |
| Nominal Zener Voltage Vz | 5.6V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 40Ω |
| Typical Voltage Temperature Coefficient | 0.25mV/°C |
| Surface Mount case | SOD-323 (SC-76) |
DiodesZetex BZT52C5V6S-7-F is a high-quality single Zener diode engineered for voltage regulation applications. It features a nominal Zener voltage of 5.6 V and is enclosed in a compact SOD-323 surface mount package, making it well-suited for modern electronic circuits where space-saving is critical.
This diode offers a maximum power dissipation of 200 mW, delivering reliable performance for low-power voltage regulation tasks. The diode maintains stable operation with a ±7% voltage tolerance and operates efficiently over a wide temperature range from -65°C to 150°C, assuring durability under varied environmental conditions.
The device possesses a maximum Zener impedance of 40 Ω at a test current of 5 mA, and the reverse leakage current is minimal at 3 μA. The typical voltage temperature coefficient is 0.25 mV/°C, ensuring consistent voltage regulation despite temperature changes.
Manufactured to meet the AEC-Q101 automotive standard, this diode is suitable for use in automotive electronics, industrial circuits, and other precision voltage regulation applications requiring stringent reliability and quality.
Its surface mount 2-pin SOD-323 case facilitates efficient PCB mounting and automated assembly processes. The compact dimensions (height 1.1 mm, length 2.7 mm) contribute to compact design implementations in consumer electronics, power supplies, and communication equipment.
Nominal Zener voltage of 5.6 V with ±7% tolerance for accurate voltage regulation. Maximum power dissipation of 200 mW supporting low-power applications. Compact SOD-323 surface mount package suitable for space-constrained PCBs.
Low reverse leakage current of 3 μA ensuring energy efficiency. Wide operating temperature range from -65°C to 150°C for reliability. Compliant with AEC-Q101 automotive standard ensuring robustness. Voltage temperature coefficient of 0.25 mV/°C maintains voltage stability.
Test current rating of 5 mA for optimal device performance.
This diode is ideal for industrial, automotive, power supply, and embedded systems requiring precise voltage regulation. For further selections of Zener Diodes, explore EnvMart's Semiconductor and Discrete Semiconductor categories.
