TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core, 1.5 μH ±30 %, 10.7 A IDC, 10165 Package SLF10165T-1R5N6R83PF
Specifications
| Country of Origin | China |
|---|---|
| Brand | TDK |
| Height | 6.5mm |
| Operating Temperature Range | - 40 to +105°C (including self-temperature rise) |
| Length | 10.1mm |
| Model | SLF10165T-1R5N6R83PF |
| Depth | 10.1mm |
| Packaging | Tape & Reel |
| Series | SLF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 1.5μH |
| Standards/Approvals | RoHS |
| Package/Case | 10165 |
| Maximum DC Current | 10.7A |
| Maximum DC Resistance | 8.71mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Compact 10165 package size suitable for space-efficient circuits.
- Magnetic shielded design to reduce electromagnetic interference.
- Wirewound construction on ferrite core for stable inductance.
- Operating temperature range from -40°C to 105°C including self-temperature rise.
- Low maximum DC resistance of 8.71 mΩ for high efficiency.
- Surface mount termination style for automated PCB assembly.
- Packaging in tape and reel format for volume manufacturing.
- RoHS compliant ensuring environmentally safe manufacturing.
Product Description
TDK SLF10165T-1R5N6R83PF is a shielded wirewound surface mount inductor featuring a ferrite core with an inductance of 1.5 μH and a tolerance of ±30 %. It supports a maximum DC current of 10.7 A, making it suitable for high-performance power circuits.
The 10165 package provides a compact footprint with dimensions of 10.1 mm length, 6.5 mm height, and 10.1 mm depth. The magnetic shield design minimizes electromagnetic interference, ensuring stable operation in sensitive electronic environments.
Constructed with wirewound technology on a ferrite core, this inductor offers high reliability and stable inductance under varying operating conditions. It operates effectively over a wide temperature range from -40°C up to 105°C, including self-temperature rise during operation.
The component exhibits a low maximum DC resistance of 8.71 mΩ, enhancing efficiency by reducing power losses. The surface mount termination style is compatible with automated PCB assembly lines and tape & reel packaging facilitates high-volume manufacturing.
This inductor complies with RoHS standards, ensuring it meets environmental safety guidelines. It is ideally used in electronic applications such as thin-screen TVs, LCD monitors, AV equipment, gaming devices, and other electrical products requiring efficient power management.
Compact 10165 package ensures space-saving design. Magnetic shielding reduces electromagnetic interference. Wide operating temperature range from -40°C to 105°C. Low resistance of 8.71 mΩ minimizes power loss. Suitable for automated surface mount PCB assembly.
RoHS certified for environmental compliance. Ideal for power circuits in TV, LCD, AV, and gaming equipment. Explore more electronics components and Surface Mount Inductors on EnvMart for reliable industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 1.5 μH with a tolerance of ±30 %.
It supports a maximum DC current of 10.7 A, making it suitable for high-performance power circuits.
The dimensions of the 10165 package are 10.1 mm in length, 10.1 mm in depth, and 6.5 mm in height.
The operating temperature range is from -40°C to +105°C, including self-temperature rise during operation.
It features a wirewound construction on a ferrite core, which provides stable inductance.
The magnetic shield design minimizes electromagnetic interference, ensuring stable operation in sensitive electronic environments.
The maximum DC resistance is 8.71 mΩ, which enhances efficiency by reducing power losses.
It has a surface mount termination style, making it compatible with automated PCB assembly.
This model is packaged in tape and reel format, which facilitates high-volume manufacturing.
Yes, it complies with RoHS standards, ensuring it meets environmental safety guidelines.
It is ideally used in electronic applications such as thin-screen TVs, LCD monitors, AV equipment, and gaming devices requiring efficient power management.
This inductor belongs to the SLF series, which is known for its compact design and efficiency.
