TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core 330 μH ±20 %, 540 mA, 10145 Package SLF10145T-331MR54-PF
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Operating Temperature Range | - 40 to +105°C (including self-temperature rise) |
| Length | 10.1mm |
| Model | SLF10145T-331MR54-PF |
| Depth | 10.1mm |
| Packaging | Tape & Reel |
| Series | SLF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 330μH |
| Standards/Approvals | RoHS |
| Package/Case | 10145 |
| Maximum DC Current | 540mA |
| Maximum DC Resistance | 816mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Constructed with a ferrite core for effective magnetic shielding.
- Wirewound construction ensures precise inductance and reliability.
- Compact 10145 package size measuring 10.1mm length, 4.5mm height, and 10.1mm depth.
- Maximum DC resistance of 816 mΩ enables efficient current handling.
- Suitable for operation in temperatures from -40°C to +105°C including self-temperature rise.
- Surface mount termination style compatible with modern PCB designs.
- Packaged in tape and reel for automated placement and assembly.
- Compliant with RoHS environmental standards.
Product Description
TDK SLF10145T-331MR54-PF is a shielded wirewound surface mount inductor designed with a ferrite core to provide efficient magnetic shielding and stable inductance in power electronic circuits. Featuring an inductance of 330 μH with a ±20 % tolerance and capable of handling a maximum DC current of 540 mA, this inductor offers reliable performance within demanding industrial and consumer electronics applications.
The inductor is packaged in a 10145 case measuring 10.1mm in length, 4.5mm in height, and 10.1mm in depth, making it compact enough for surface mounting on printed circuit boards. Its construction ensures a maximum DC resistance of 816 mΩ, supporting efficient current flow with minimal energy loss. The device is rated for operation over a wide temperature range from -40°C to +105°C including self-temperature rise, ensuring durability under diverse environmental conditions.
Packaging in tape and reel format supports automated manufacturing processes. The device complies with RoHS standards, reflecting its suitability for environmentally conscious electronic designs. The surface mount termination style facilitates easy integration into modern electronic assemblies.
Common applications include usage in thin-screen televisions, LCD panels, audio-visual equipment, gaming hardware, and other electrical devices requiring stable power inductors with shielded magnetic characteristics. This product is well-suited for both commercial and industrial electronics manufacturing environments.
Ferrite core magnetic shielding enhances performance and reduces electromagnetic interference. Wirewound design delivers stable inductance and robust electrical characteristics. Compact 10145 package optimizes space on printed circuit boards.
Wide operating temperature range supports reliability in diverse environments. RoHS compliant, meeting environmental and safety regulations. Surface mount termination allows for automated assembly and soldering. Low DC resistance ensures efficient current conduction.
Packaged in tape and reel for streamlined manufacturing integration. Ideal for power circuits in consumer electronics and industrial applications. Explore more Surface Mount Inductors and related TDK products on EnvMart for advanced electronics component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 330 μH with a tolerance of ±20%.
The maximum DC current for this inductor is 540 mA.
The dimensions of the package are 10.1 mm in length, 4.5 mm in height, and 10.1 mm in depth.
The maximum DC resistance is 816 mΩ, which supports efficient current flow.
It can operate in temperatures ranging from -40°C to +105°C, including self-temperature rise.
This inductor is constructed with a ferrite core, providing effective magnetic shielding.
The termination style is surface mount, which is compatible with modern PCB designs.
It is packaged in tape and reel format, facilitating automated placement and assembly.
Yes, it complies with RoHS environmental standards.
Common applications include thin-screen televisions, LCD panels, and audio-visual equipment.
This model utilizes a wirewound construction, ensuring stable inductance and reliability.
It belongs to the SLF series of inductors.
