Vishay Rectifier & Schottky Diode, 200V 5A, DO-221AC Package, Surface Mount Schottky VSSAF522HM3/H
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1mm |
| Length | 5.35mm |
| Model | VSSAF522HM3/H |
| Width | 2.7mm |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-221AC |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS and AEC-Q101, JESD 201 Class 2 whisker test |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 5A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 50μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 90A |
| Maximum Forward Voltage Vf | 0.9V |
Key Features
- High efficiency Schottky diode suitable for rectification and polarity protection.
- Rated at 200V peak reverse repetitive voltage and 5A maximum continuous forward current.
- DO-221AC surface-mount package allows low-profile PCB applications.
- Features low forward voltage drop at 0.9V for reduced power losses.
- Qualified to automotive AEC-Q101 standard for reliability.
- Wide operating temperature range from -40°C to 175°C supports robust environments.
- Trench MOS Schottky technology for superior performance and efficiency.
- RoHS compliant and meets JESD 201 Class 2 whisker test standards.
Product Description
Vishay VSSAF522HM3/H is a high-performance rectifier and Schottky diode engineered for demanding electronic applications. Designed with Trench MOS Schottky technology, this component delivers exceptional efficiency with low power losses and a low forward voltage drop of 0.9V, supporting critical requirements in commercial, industrial, and automotive sectors.
High efficiency Schottky diode suitable for rectification and polarity protection. Rated at 200V peak reverse repetitive voltage and 5A maximum continuous forward current. DO-221AC surface-mount package allows low-profile PCB applications.
Features low forward voltage drop at 0.9V for reduced power losses. Qualified to automotive AEC-Q101 standard for reliability. Wide operating temperature range from -40°C to 175°C supports robust environments. Trench MOS Schottky technology for superior performance and efficiency.
RoHS compliant and meets JESD 201 Class 2 whisker test standards.
Its surface-mount DO-221AC package ensures a low profile and is ideal for automated placement in high-volume PCB manufacturing. The diode is AEC-Q101 qualified, ensuring suitability for automotive and industrial systems, including high-frequency inverters, DC/DC converters, freewheeling, and polarity protection.
With a maximum continuous forward current of 5A and a peak reverse repetitive voltage of 200V, the VSSAF522HM3/H is especially valuable for efficient power conversion and circuit protection. The peak non-repetitive forward surge current is rated at 90A, supporting transient loads in durable electronics designs.
A wide operating temperature range from -40°C to 175°C provides flexibility for installations in harsh environments, including automotive, industrial, and commercial applications. The low reverse leakage current of 50μA adds to overall energy efficiency.
The Vishay VSSAF522HM3/H is compliant with RoHS standards and passes the JESD 201 Class 2 whisker test, meeting strict requirements for reliability and safety. Standard applications include use in inverter circuits, DC/DC converters, freewheeling circuits, and polarity protection in industrial controls, automotive electronics, and power systems.
Browse more Vishay semiconductors and Schottky Diodes in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak reverse repetitive voltage rating of this model is 200V.
This diode has a maximum continuous forward current rating of 5A.
The maximum forward voltage drop for this Schottky diode is 0.9V.
The dimensions of the DO-221AC package are 5.35mm in length, 2.7mm in width, and 1mm in height.
The operating temperature range for this model is from -40°C to 175°C.
Yes, this diode is qualified to the AEC-Q101 automotive standard, making it suitable for automotive applications.
The peak non-repetitive forward surge current for this model is rated at 90A.
This diode is RoHS compliant and meets JESD 201 Class 2 whisker test standards.
The reverse leakage current for this Schottky diode is rated at 50μA.
This model uses a surface mount type for installation.
The VSSAF522HM3/H is suitable for applications such as inverter circuits, DC/DC converters, freewheeling circuits, and polarity protection.
This diode utilizes Trench MOS Schottky technology, which enhances its performance and efficiency.
