Abracon 14.7456 MHz Crystal Unit, ±20 ppm, Surface Mount, 18pF Load, 4-Pin, 3.2 x 2.5 x 1 mm, ABM8G-14.7456MHZ-18-D2Y-T
Specifications
| Country of Origin | China |
|---|---|
| Brand | Abracon |
| Height | 1mm |
| Length | 3.2mm |
| Model | ABM8G-14.7456MHZ-18-D2Y-T |
| Packaging | Tape & Reel |
| Width | 2.5mm |
| Mount Type | Surface |
| Series | ABM8G |
| Maximum Operating Temperature | 85°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | REACH, RoHS |
| Pin Count | 4 |
| Standard Frequency | 14.7456MHz |
| Load Capacitance | 18pF |
| Series Resistance | 80Ω |
Key Features
- Surface mount crystal unit operating at 14.7456 MHz with ±20 ppm frequency tolerance.
- Low profile design at just 1 mm height, ideal for slim equipment and high-density PCBs.
- 18 pF load capacitance, tape and reel packaging, and 4-pin termination for ease of assembly.
- Glass-sealed package ensures improved reliability and stability over a wide temperature range of -40°C to +85°C.
- IR reflow compatible for modern automatic assembly processes.
- Perfect for modems, communication, and test equipment, as well as PCMCIA and wireless applications.
- Meets REACH and RoHS compliance for global regulatory standards.
Product Description
The Abracon ABM8G-14.7456MHZ-18-D2Y-T is a precision surface mount crystal unit engineered to provide a stable frequency reference of 14.7456 MHz. This device is designed with high reliability in mind, featuring a glass-sealed package that ensures consistent performance even under demanding operating conditions. Its compact form factor with a low profile of just 1 mm height enables integration into space-constrained or slim electronic equipment without sacrificing stability.
Offering a frequency tolerance of ±20 ppm and frequency stability of ±30 ppm, this crystal provides reliable timekeeping and signal reference required in advanced electronics. Its standard load capacitance of 18 pF supports compatibility with a wide range of oscillator circuits, making it a versatile option for designers of communication modules, test instrumentation, or embedded devices.
This model has a surface mount design and tape-and-reel packaging, supporting automated pick-and-place manufacturing for high-volume assembly lines. The IR reflow-compatible construction streamlines the soldering process and further increases assembly efficiency. A 4-pin configuration offers secure electrical connections and optimized signal transfer.
The ABM8G-14.7456MHZ-18-D2Y-T crystal is robust across a broad temperature range, from -40°C up to 85°C, and boasts a series resistance of 80 Ohms. It is compliant with global regulatory standards such as REACH and RoHS, which is essential for international product development and export. Its low cost and stable performance make it a preferred choice in industries requiring precise frequency control, such as modem production, communication interfaces, wireless modules, and portable electronic devices.
This high-density, glass-sealed crystal is particularly recommended for high-reliability applications where component longevity and operational stability are critical. Its minimal size and low height render it suitable for stacked assemblies and compact circuit designs with rigorous spacing constraints. The Abracon ABM8G-14.7456MHZ-18-D2Y-T delivers performance and consistency, making it a trusted component for professionals in the electronics manufacturing and design sectors.
Browse more Abracon crystal units and explore advanced frequency control solutions for your critical design needs in the Crystals, Oscillators & Resonators category on EnvMart.
Explore more products in our Crystals, Oscillators & Resonators category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The standard frequency of this model is 14.7456 MHz, providing a stable frequency reference for various applications.
This crystal unit has a frequency tolerance of ±20 ppm, ensuring reliable performance in precise timing applications.
The dimensions of this model are 3.2 mm in length, 2.5 mm in width, and 1 mm in height, making it suitable for compact designs.
It has a standard load capacitance of 18 pF, which supports compatibility with a variety of oscillator circuits.
The operating temperature range for this model is from -40°C to 85°C, allowing it to function reliably in diverse environments.
This unit is packaged in tape and reel format, facilitating automated assembly processes.
This crystal unit features a 4-pin configuration, which provides secure electrical connections.
The series resistance for this model is 80 Ohms, which is relevant for its performance in circuits.
Yes, the ABM8G-14.7456MHZ-18-D2Y-T meets both REACH and RoHS compliance standards, making it suitable for global markets.
This crystal unit is ideal for applications in modems, communication devices, test equipment, and wireless modules.
It utilizes a surface mount design, which is beneficial for high-density PCB layouts.
The maximum operating temperature for this model is 85°C, ensuring it can withstand higher thermal environments.
