IQD GPS Disciplined 10MHz Oscillator ±10 ppb 14-Pin HCMOS Through Hole LFOCXO065520B
Specifications
| Country of Origin | India |
|---|---|
| Brand | IQD |
| Model | LFOCXO065520B |
| Packaging | Loose in Bulk Pack |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 75°C |
| Output Frequency | 10MHz |
| Minimum Operating Temperature | -20°C |
| Standards/Approvals | EU, REACH Status, RoHS Status 2011 |
| Pin Count | 14 |
| Minimum Supply Voltage | 5V |
| Load Capacitance | 15pF |
| Output Level | HCMOS |
Key Features
- Operates at a frequency of 10 MHz with ±10 parts per billion stability.
- Equipped with 14 pins supporting HCMOS output level.
- Designed for through hole mounting with 15pF load capacitance.
- Operates stably in temperatures ranging from -20°C to 75°C.
- Minimum and maximum supply voltage maintained at 5V for optimal performance.
- Compatible with GPS, GLONASS, BEIDOU, and GALILEO synchronization using 1PPS input and output.
- Holdover stability achieved up to 1.5 microseconds over 24 hours at ±5°C deviation.
- Complies with EU, REACH, and RoHS standards ensuring quality and environmental safety.
Product Description
IQD LFOCXO065520B is a precision GPS disciplined OCXO oscillator designed for applications requiring unsurpassed frequency stability and synchronization. This model operates at 10 MHz frequency with remarkable ±10 parts per billion frequency stability, providing reliable performance for critical timing and frequency control systems.
The oscillator features a 14-pin through hole mount configuration with HCMOS output level and a load capacitance of 15pF. Its operating voltage range is fixed at 5V, ensuring stable electrical characteristics. It is engineered to operate seamlessly across a temperature range from -20°C to 75°C, suitable for various environmental conditions encountered in industrial, laboratory, and telecommunications installations.
This oscillator incorporates GPS discipline capabilities, synchronizing with GPS, GLONASS, BEIDOU, and GALILEO constellation systems via 1PPS input and output signals. It achieves holdover stability up to 1.5 microseconds over a 24-hour period referenced at ±5°C, making it ideal for precision timing applications in navigation, communications, and metrology.
Operates at 10 MHz frequency with ±10 ppb stability. Features 14-pin through hole mounting with HCMOS output. Load capacitance of 15 pF ensures optimal load matching. Operating temperature range from -20°C to 75°C supports diverse environments.
Supply voltage fixed at 5V for consistent operation. GPS disciplined oscillator compatible with multiple satellite systems. Holdover stability up to 1.5 microseconds over 24 hours at ±5°C. Certified compliant with EU, REACH, and RoHS environmental standards.
Packaged loose in bulk format for volume industrial applications.
This oscillator is ideal for industrial, laboratory, telecommunications, and aerospace uses requiring stable, high-precision frequency references. Its robust build and certified compliance ensure reliability and environmental safety for critical electronic designs.
Explore more electronic oscillators and timing components from EnvMart's extensive catalog to find exact matches for your precision timing and synchronization needs.
Explore more products in our Crystals, Oscillators & Resonators category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The oscillator operates at an output frequency of 10 MHz.
It has a frequency stability rating of ±10 parts per billion (ppb).
This model operates within a temperature range of -20°C to 75°C.
It features an HCMOS output level.
The load capacitance for this oscillator is 15 pF.
This oscillator has a total of 14 pins.
The minimum supply voltage for this model is fixed at 5V.
It complies with EU, REACH, and RoHS standards.
The holdover stability is up to 1.5 microseconds over a 24-hour period at ±5°C deviation.
This oscillator is designed for through hole mounting.
The oscillator is manufactured in India.
It is suitable for applications in industrial, laboratory, telecommunications, and aerospace requiring stable frequency references.
