IQD 40MHz Surface Mount Temperature Compensated Voltage Controlled Oscillator Ceramic Package LFTVXO009912
Specifications
| Country of Origin | India |
|---|---|
| Brand | IQD |
| Height | 2mm |
| Length | 7mm |
| Model | LFTVXO009912 |
| Width | 5mm |
| Mount Type | Surface |
| Series | LFTVXO |
| Maximum Operating Temperature | 85°C |
| Output Frequency | 40MHz |
| Package Type | Ceramic package |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS, REACH, MSL, JDEC-STD-033 |
| Pin Count | 4 |
| Maximum Supply Voltage | 3.3V |
| Minimum Supply Voltage | 1.65V |
| Load Capacitance | 15pF |
| Output Level | HCMOS |
Key Features
- Operates at a fixed output frequency of 40MHz.
- Temperature compensated for ±0.5 ppm frequency stability.
- Compact hermetically sealed ceramic package measuring 7 x 5 x 2 mm.
- Compatible with HCMOS output level for digital circuits.
- Supports supply voltage from 1.65V to 3.3V.
- Suitable for operation between -40°C to 85°C temperature range.
- Features a pin count of 4 for surface mount applications.
- Meets RoHS, REACH, MSL, and JDEC-STD-033 standards.
Product Description
IQD LFTVXO009912 is a surface mount temperature compensated voltage controlled oscillator (TCVCXO) designed for applications requiring exceptional frequency stability and precision. Operating at a fixed output frequency of 40MHz, this oscillator provides a stability of ±0.5 ppm over a wide temperature range, ensuring reliable performance in various industrial and electronic environments.
The device encases its internal components within a hermetically sealed ceramic package measuring 7mm in length, 5mm in width, and 2mm in height, enhancing durability and environmental resistance. The HCMOS output level ensures compatibility with modern digital circuits and microcontrollers.
Designed to operate within a supply voltage range of 1.65V to 3.3V, the oscillator supports flexibility in power requirements. It is suitable for use in temperature conditions from -40°C to 85°C, making it fit for industrial, laboratory, and commercial electronic equipment.
Its 4-pin surface mount configuration facilitates easy PCB integration in compact assembly designs. The product complies with industry regulatory standards including RoHS, REACH, MSL, and JDEC-STD-033, reinforcing its environmental and quality assurances.
Operates at a fixed output frequency of 40MHz. Provides ±0.5 ppm frequency stability across temperature variations. Hermetically sealed in a compact ceramic package. HCMOS output level for digital interface compatibility.
Wide operating supply voltage from 1.65V to 3.3V. Supports a temperature range of -40°C to 85°C. 4-pin surface mount package type. Complies with RoHS, REACH, MSL, and JDEC-STD-033 standards. Suitable for industrial, laboratory, and commercial applications requiring precise timing.
This TCVCXO oscillator by IQD is a reliable choice for enhancing timing accuracy and stability in electronic devices, including instrumentation, communication systems, and control equipment. Browse the Electronics Components category on EnvMart for similar precision oscillator solutions.
Explore more products in our Crystals, Oscillators & Resonators category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at a fixed output frequency of 40MHz.
This model is suitable for operation between -40°C to 85°C.
It provides a frequency stability of ±0.5 ppm over its operating temperature range.
It supports an HCMOS output level, making it compatible with digital circuits.
The ceramic package measures 7mm in length, 5mm in width, and 2mm in height.
It operates within a supply voltage range of 1.65V to 3.3V.
It features a 4-pin configuration for surface mount applications.
It complies with RoHS, REACH, MSL, and JDEC-STD-033 standards.
The load capacitance is specified at 15pF.
The country of origin for this product is India.
This model is part of the LFTVXO series.
It is suitable for industrial, laboratory, and commercial applications requiring precise timing.
