Abracon Surface Mount Crystal Unit 20 MHz ±25 ppm 2-Pin, 4.1 mm x 11.4 mm x 4.7 mm ABLS-20.000MHz-20-B-3-H-T

The Abracon ABLS-20.000MHz-20-B-3-H-T is a highly reliable surface mount crystal unit engineered for precision circuit timing in electronic systems. This 2-pin crystal provides a standard frequency of 20 MHz with tight tolerance of ±25 ppm and frequency stability of ±35 ppm, enabling consistent and accurate operation in demanding applications.

Constructed for surface mount integration, the crystal features compact dimensions - 4.1 mm in height, 11.4 mm in length, and 4.7 mm in width - allowing easy placement on modern printed circuit board layouts. The load capacitance of 20 pF optimizes performance for microprocessor, modem, and wireless applications requiring stable oscillation and signal integrity.

The unit accommodates a wide operating temperature range from -20°C to 70°C, ensuring adaptability for computers, modems, microprocessors, wireless modules, and other industrial electronics. Tape and reel packaging simplifies incorporation into high-volume automated assembly lines for commercial and industrial manufacturing.

With a series resistance of 40 Ω and 2-pin configuration, the Abracon crystal maintains robust electrical characteristics for stable operation. RoHS compliance assures environmentally responsible manufacturing processes and dependable long-term performance.

Typical industrial and commercial use cases include circuit timing, clock generation, synchronization in embedded controls, and frequency reference in communication systems. Applications span sectors such as telecommunications, computing, industrial automation, laboratory instrumentation, and consumer electronics where clock accuracy is essential.

Surface mount crystal unit with 2-pin configuration. Standard frequency of 20 MHz, ideal for precise timing control. Offers ±25 ppm frequency tolerance and ±35 ppm stability. Compact dimensions: 4.1 mm height, 11.4 mm length, and 4.7 mm width.

Robust load capacitance of 20 pF for efficient signal performance. Operating temperature from -20°C to 70°C suitable for diverse environments. Supports tape and reel packaging for automated assembly processes. RoHS-compliant for dependable quality and environmental standards.
