| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 0.65mm |
| Length | 1.25mm |
| Model | PMEG3010EB,115 |
| Width | 0.85mm |
| Mount Type | Surface |
| Series | PMEG3010EB |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-523 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 5A |
| Maximum Forward Voltage Vf | 680mV |
Nexperia PMEG3010EB,115 is a high-efficiency Schottky Barrier Diode featuring a maximum continuous forward current of 1 ampere and a peak reverse voltage of 30 volts. Packaged in a compact 2-pin SOD-523 surface mount package, this diode is suited for applications demanding low forward voltage drop and high temperature resistance. Its low leakage current and optimized low capacitance properties contribute to minimal power dissipation, making it ideal for fast switching and rectification in automotive, industrial, and consumer electronics.
The diode supports extended operating temperatures from -65°C up to 150°C and conforms to the AEC-Q101 automotive standard, highlighting its robustness for automotive circuit protection and power management tasks. Its small dimensions (height 0.65 mm, length 1.25 mm, width 0.85 mm) enable integration in densely packed printed circuit boards where space conservation is critical.
This Schottky diode offers reliable rectification in power supply circuits, voltage clamping, and freewheeling diode applications, supporting peak non-repetitive surge currents of up to 5 amperes. Its negligible switching power losses and high junction temperature tolerance make it suitable for high-frequency switching power supplies and converters.
Surface mount SOD-523 package enables compact PCB design. High forward current and surge current capability provide operational stability. Low forward voltage reduces heat generation improving efficiency. Wide operating temperature range suits harsh automotive and industrial environments.
Low leakage current ensures minimal power loss during operation. Meets automotive reliability standard AEC-Q101. Small form factor dimensions facilitate space optimization in designs. Optimized low capacitance enhances high-frequency performance.
Reliable protection in power rectification and voltage clamping applications.
Overall, the PMEG3010EB,115 diode by Nexperia combines compact size with high performance making it a preferred choice for demanding Schottky diode applications in various industrial, automotive, and electronic equipment.
