onsemi Small Signal NPN Transistor 100 mA 45 V 3-Pin SOT-323 BC847AWT1G

onsemi BC847AWT1G small signal NPN transistor is designed for compact surface mount applications requiring reliable switching and amplification. Featuring a maximum collector current of 100 mA and collector-emitter voltage of 45 V, this transistor supports a variety of electronics and automotive system designs requiring moderate power handling and switching speed.

The device is housed in a tiny 3-pin SOT-323 package measuring 2.2 mm in length, 1.35 mm in width, and 1 mm in height. Its surface mount configuration facilitates straightforward integration on modern printed circuit boards. Rated for operation in temperatures from -55°C to 150°C and automotive qualified to the AEC-Q101 standard, it is suited for demanding industrial and automotive environments.

With a minimum DC current gain of 110 and a transition frequency of up to 100 MHz, the BC847AWT1G transistor offers effective amplification in signal processing and switching circuits. The maximum power dissipation rating of 150 mW aligns with low power applications such as sensors, signal conditioning, and control circuitry.

Maximum DC collector current of 100 mA ensures reliable signal amplification. Collector-emitter voltage rated at 45 V for medium voltage switching applications. Compact surface mount SOT-323 package with 3 pins for efficient PCB layout.

High gain with minimum DC current gain (hFE) of 110 for effective amplification. Automotive-qualified to AEC-Q101 standard, suitable for harsh environments. Wide operating temperature range from -55°C to 150°C for robust use.

Maximum power dissipation of 150 mW supports small signal applications. Transition frequency up to 100 MHz enabling high-speed switching. Pin count of 3 in a low-profile device measuring 2.2 mm length, 1.35 mm width, and 1 mm height.

NPN transistor polarity for versatile circuit designs.

This transistor is ideal for use in industrial control systems, automotive electronics, instrumentation, communications equipment, and general purpose amplification circuits. Its automotive qualification and broad temperature range make it highly reliable for harsh environment applications.

Explore more on bipolar transistor offerings in the semiconductor category for comprehensive electronics design solutions.
