Samtec Coaxial Connector Cable Female MCX 50 Ω Right Angle Body Edge Mount MMCX-P-C-H-ST-CA1
Specifications
| Country of Origin | India |
|---|---|
| Size | Standard |
| Brand | Samtec |
| Orientation | Right Angle |
| Model | MMCX-P-C-H-ST-CA1 |
| Mount Type | Cable |
| Operating Frequency | 6GHz |
| Contact Material | Beryllium Copper Alloy |
| Series | MIMCX |
| Termination Type | Edge Mount |
| Maximum Operating Temperature | 125°C |
| Cable Type | RG174, RG-316 |
| Minimum Operating Temperature | -65°C |
| Polarity | Normal |
| Impedance | 50Ω |
| Contact Plating | Gold |
| Contact Gender | Female |
| Connector Gender | Female |
| Coaxial Connector Type | MCX |
| Body Plating | Gold |
Key Features
- This coaxial connector is designed for a frequency range up to 6 GHz.
- It features a female connector gender with gold-plated beryllium copper alloy contacts for enhanced conductivity.
- The termination type is edge mount suitable for PCB connections.
- The cable types compatible are RG174 and RG-316, ensuring versatility in applications.
- It operates reliably between -65°C to 125°C, providing durability in extreme environments.
- The connector is part of the MIMCX series, ideal for RF coaxial connectivity.
- The normal polarity design supports standard signal flows.
- Its compact standard size allows easy integration into various electronic assemblies.
Product Description
Samtec MMCX-P-C-H-ST-CA1 is a high-performance Coaxial Connector Cable Female MCX designed for precise 50 Ω impedance applications. This right angle body edge mount connector facilitates optimized signal integrity, suitable for demanding RF applications up to 6 GHz.
The connector features gold-plated beryllium copper alloy contacts that ensure excellent electrical conductivity and long-term durability. Its edge mount termination type allows seamless soldering onto printed circuit boards, making it ideal for compact electronic assemblies.
The compatible cable types, RG174 and RG-316, provide flexibility for diverse cabling needs in telecommunications, aerospace, and instrumentation industries. Its operating temperature range from -65°C to 125°C ensures reliable performance in harsh environmental conditions. The gold body plating enhances corrosion resistance while maintaining superior electrical characteristics.
This connector belongs to the MIMCX series, recognized for precision and reliability in RF coaxial connectivity. The product features a female connector gender with normal polarity, supporting standard antenna and signal connections.
Its standard size and no bulkhead design facilitate easy integration without added bulk, suitable for space-constrained applications in industrial and commercial electronics. This coaxial connector supports operating frequencies up to 6 GHz.
Gold-plated beryllium copper contacts provide excellent conductivity. Edge mount termination enables PCB soldering. Compatible with RG174 and RG-316 cable types. Operates within a temperature range of -65°C to 125°C. Right angle body orientation for flexible cable routing.
Gold body plating offers corrosion resistance. Standard size design for easy integration. Female connector gender with normal polarity. Part of the reliable and precise MIMCX series.
This connector cable is suited for industrial, laboratory, telecommunications, and aerospace applications, offering robust performance and signal integrity. Explore more in Coaxial Connectors category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating frequency of this connector is 6 GHz, making it suitable for demanding RF applications.
This model is compatible with RG174 and RG-316 cable types, providing versatility for various applications.
It operates reliably within a temperature range of -65°C to 125°C, ensuring performance in extreme environments.
The contacts are made of gold-plated beryllium copper alloy, which enhances electrical conductivity and durability.
This connector features an edge mount termination type, allowing for seamless soldering onto printed circuit boards.
This model has a right angle body orientation, which facilitates flexible cable routing in tight spaces.
The impedance rating of this connector is 50 Ω, suitable for precise RF applications.
This connector has a female gender, designed for standard antenna and signal connections.
This connector is part of the MIMCX series, known for its reliability and precision in RF coaxial connectivity.
The body of this connector is gold-plated, which offers enhanced corrosion resistance and maintains superior electrical characteristics.
This connector is suitable for applications in telecommunications, aerospace, industrial, and laboratory environments, offering robust performance.
This connector is classified as a standard size, allowing for easy integration into various electronic assemblies.
