Samtec IPL1 Series Straight Through Hole PCB Header, 8 Contact, 2.54 mm Pitch, 1 Row, Shrouded IPL1

Samtec IPL1 Series Straight Through Hole PCB Header (Model IPL1) is a high-quality wire-to-board connector featuring 8 contacts arranged in a single row at a 2.54 mm pitch. This component is manufactured in the United States using robust liquid crystal polymer housing, ensuring excellent mechanical strength and thermal stability.

The PCB header incorporates phosphor bronze contacts plated with gold, enhancing electrical conductivity and corrosion resistance. Designed for through-hole mounting, it has a tail pin length of 3.05 mm and uses solder termination for stable connections.

Operating reliably within a temperature range of -55°C to 125°C, this PCB header supports voltages up to 954 volts and current ratings reaching 3.8 amperes at 95°C. The straight orientation and shrouded contact design facilitate secure and precise mating, protecting contacts during handling and assembly.

Housing material: liquid crystal polymer for durability and thermal resistance. Contact material: phosphor bronze with gold plating ensures excellent conductivity. Mount type: through hole with solder termination for secure PCB connection.

Operating temperature range suitable for industrial and electronic applications. Voltage rating up to 954 V supports a wide range of electronic circuits. Single row, 8 contacts arranged at industry standard 2.54 mm pitch.

Shrouded connector system enhances protection and durability upon usage. Ideal for use in electronics manufacturing, prototyping, and system integration.

This connector is a reliable solution for PCB interfacing in commercial, industrial, and laboratory applications where durable and precise electrical contacts are critical. It is compliant with standard electronic component requirements and designed for long-term use.
