| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.11mm |
| Length | 3.04mm |
| Model | MMBTA92LT1G |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | MMBTA92L |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | -300V |
| Minimum DC Current Gain hFE | 25 |
| Transistor Polarity | PNP |
| Maximum Emitter Base Voltage VEBO | 5V |
| Maximum Collector Base Voltage VCBO | 300V |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 300mW |
| Maximum DC Collector Current Idc | -500mA |
| Transistor Configuration | Single |
| Maximum Transition Frequency ft | 50MHz |
onsemi MMBTA92LT1G is a PNP bipolar transistor featuring a 3-Pin SOT-23 surface mount package. It supports a maximum DC collector current of -500 mA and a maximum collector emitter voltage of -300 V, making it suitable for a variety of electronic applications requiring medium power and high voltage tolerance.
This transistor is designed for compact circuits where space is limited but performance and reliability are essential. It has a maximum power dissipation of 300 mW and a transition frequency of 50 MHz, supporting moderate-frequency switching and amplification tasks.
The operating temperature range from -55°C to 150°C enables usage in demanding industrial and automotive environments. The device is qualified to the AEC-Q101 automotive standard, ensuring robustness and longevity in automotive electronic systems.
The physical dimensions of the transistor are 3.04 mm in length, 1.4 mm in width, and 1.11 mm in height, making it compatible with standard surface mount technology (SMT) production processes.
This component is ideally used in industrial, automotive, consumer electronics, and power management applications where a reliable PNP transistor is required. Designed for surface mount applications with SOT-23 package. Maximum collector emitter voltage of -300 V for high voltage performance.
Single transistor configuration suited for switching and amplification. Maximum power dissipation of 300 mW enables moderate power applications. Operating temperature range from -55°C to 150°C for harsh environments. Compliance with AEC-Q101 automotive standard ensures reliability.
High transition frequency of 50 MHz suitable for high-speed circuits. Compact dimensions with height 1.11 mm, length 3.04 mm, and width 1.4 mm. Minimum DC current gain of 25 supports amplification requirements. Pin count of 3 pins compatible with standard PCB layouts.
Explore the onsemi MMBTA92LT1G and related Bipolar Transistors at EnvMart for your semiconductor component needs.
